 Deck Lashing Turnbuckle with Pelican Hook and Pear Link

 LGRIG® Hamburger Turnbuckle Lashing Marine D D

 LGRIG® Turnbuckle Commercial Eye/Eye Cast Steel DIN1480

Shackles 

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Hamburger Turnbuckle Lashing Marine D D

Brand	LGRIG®
Material	Super Mild Steel
Processing	Welded
Finish	Self-colored, Electro-Galvanized, Hot dip Galvanized
Size	M24, M27, M30, M38
Country of Origin	China

Specifications of LGRIG® Hamburger Turnbuckle Lashing Marine D D


Part No.	Dimension(mm)										Breaking Load	Weight
Part No.	M	A	B	C	D	H	1	2	R1	R2	(T)	(kg/pc)
LGHTDD01	24	400	75	35	210	22	16	12	615	20	13	2.9
LGHTDD02	24	400	75	35	210	36	18	12	15	20	18	2.9
LGHTDD03	24	500	75	35	260	22	16	12	15	20	13	3.4
LGHTDD04	24	500	75	35	260	36	18	12	15	20	18	3.4
LGHTDD05	27	400	75	35	210	33	20	12	17.5	21.5	20	4
LGHTDD06	27	400	75	35	210	42	20	12	17.5	21.5	25	4
LGHTDD07	27	500	75	35	260	33	20	12	17.5	21.5	20	4.6
LGHTDD08	27	500	75	35	260	42	20	12	17.5	21.5	25	4.6
LGHTDD09	30	400	75	35	210	–	–	12	17.5	25.5	–	4.5
LGHTDD10	30	400	75	35	210	45	22	12	17.5	25.5	25	4.5
LGHTDD11	30	500	75	35	260	–	–	12	17.5	25.5	–	5.5
LGHTDD12	30	500	75	35	260	45	22	12	17.5	25.5	25	5.5
LGHTDD13	38	480	80	35	255	40	25	12	20	28	30	7.6
LGHTDD14	38	480	80	35	–	–	–	–	–	–	–	9
