LGRIG®-swageless-thread-terminal-stainless-steel-316
LGRIG®-swageless-thread-terminal-stainless-steel-316
LGRIG®-swageless-thread-stud-terminal-stainless -steel-wire-rope-swageless-fittings-thread-stud
LGRIG®-swageless-thread-stud-terminal-stainless -steel-wire-rope-swageless-fittings-thread-stud
LGRIG®-swageless-thread-stud-terminal-stainless-steel-316-wire-rope-fitting
LGRIG®-swageless-thread-stud-terminal-stainless-steel-316-wire-rope-fitting
LGRIG®-swageless-stud-terminal-stainless-steel-316
LGRIG®-swageless-thread-terminal-stainless-steel-316
LGRIG®-swageless-thread-stud-terminal-stainless -steel-wire-rope-swageless-fittings-thread-stud
LGRIG®-swageless-thread-stud-terminal-stainless-steel-316-wire-rope-fitting

LGRIG® Swageless Stud Terminal Stainless Steel

LGRIG® Swageless Stud Terminal, also known as Swageless Thread Terminal.

The Cable Railing Swageless Stud Terminal can be combined with the Cable Railing Swageless Jaw Terminal to create a unique style.

This swageless stud terminal fits perfectly for wood posts, and for smaller wood posts or metal posts, simply cut the excess thread.

The swageless stud terminal can fit any cable railing project and is ideal for marine, industrial, and architectural applications.

Our Swageless Stud Terminal is suitable for both indoor and outdoor cable rail projects, with tensioning achieved by screwing the lock nut clockwise; once tensioning is complete, cut the excess thread and install the acorn nut.

These Stainless Steel Swageless Screwed Terminals are used to terminate wire rope and are manufactured from 316 Grade Stainless Steel for excellent long-lasting corrosion resistance.

These swageless terminals are easier to use than swaged versions as they require no additional tools, allowing for easy installation anywhere, onsite or at home, making a professional-looking wire balustrade easier to achieve than ever.

Get A Quote
Products
Trawling Gear
Trawling Swivel
Hooks
Trawling Shackle
Rope Thimbles
Rings & Links
Kelly's Eye & Stoppers
G-Hooks & Recessed Links
Connectors
Tools
Rockhopper Spare Parts
Trawling Chain
Synthetic Rope
Trawl Wire
Anchors & Fittings
Wire Rope Clips
Ferrules & Terminals
Rigging Screws
Fishing Net Float
Fenders & Buoys
Lashing/Slings/Load Binders
Trawl Blocks & Pulley
Toggles & Spacers
Safety Appliance
Footrope Gear
Lifting & Rigging
G100 Products
G80 Products
Turnbuckles
Shackles
Eye Bolts & Nuts
Rigging Hooks
Swivels
Forged Rings & Connector
Quick Links
Snap Hooks
Wire Rope
Wire Rope Thimbles
Wire Ropes Clips & Grips
Wire Rope Sleeves/Ferrules
Chains & Accessories
Chain Binders
Ratchet Straps
Lifting Sling of Lifting & Rigging
Lever Hoist
Pulley & Blocks
Lifting & Rigging Pins
Forestry Logging Supplies
Eye Plate
Stainless Steel Products
Shade Sail Hardware
Stainless Shackles
Stainless Turnbuckle
Stainless Eye Bolts & Nuts
Stainless Thimbles
Stainless Rings
Stainless Swivels
Stainless Quick Link
Stainless Wire Clips
Stainless Hooks & Clips
Stainless Terminals
LGRIG® Stainless Steel Swage Jaw Terminal
LGRIG® Stainless Steel Swage Eye Terminal
LGRIG® Stainless Steel Swage Stud Terminal
LGRIG® Stainless Steel Dome Head Terminal
LGRIG® Stainless Steel Swage Toggle Terminal
LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing
LGRIG® Stainless Steel Swage Toggle Terminal U.S. Type (thin-wall)
LGRIG® Stainless Steel Swage Machined Fork Terminal
LGRIG® Swageless Fork Terminal Stainless Steel
LGRIG® Stainless Steel Swageless Eye Terminal
LGRIG® Swageless Deck Toggle Stainless Steel
LGRIG® Swageless Stud Terminal Stainless Steel
LGRIG® Swageless Lag Screw Terminal Stainless Steel
LGRIG® Swageless Cone Toggle Terminals Stainless Steel
Stainless U Bolts
Stainless Hinge
Stainless Pulleys
Drop Forged Stainless Products
Stainless Chains
Eye Plate, Eye Straps, Angles
Boat Fittings
Stainless Marine Hinges
Bimini Top Fittings
Cleats & Fairleads
Angle Bracket
Rail Fittings
Thru-Hull & Deck Fittings
Stainless Latches
Mooring Compensators / Springs
Brake Lining
Pole Line Hardware
A-Cable Suspension Bolt-China LG Manufacture
Adjusting Plate for Power Line-China LG Manufacture
Angle Eye Bolt Pole Line Hardware-China LG Supply
Cable Span Clamps Pole Line Hardware-China LG Manufacture
Carriage Bolts For Overhead Line Construction-China LG Supply
Crossover Clamp-China LG Manufacture
Electric Power Bow/Dee Shackle for Power Line-China LG Supply
Electric Power Eye Shaft Screw Anchor-China LG Supply
Electric Power Socket Clevis WSY-China LG Manufacture
Electric Power Socket Clevis-Double Type-Line Hardware-LG RIGGING®
Electric Power Socket Clevis-Single Type-Line Hardware-China LG Supply
Electric Power Thimble Eye Nut-China LG Manufacture
Electric Power U Ball Clevis-China LG Manufacture
Electrical Wire Cable Thimble Clevis-China LG Supply
Forged Eye Bolt For Anchor Assemble-China LG Supply
Forged Oval Eye Nut for Pole Line Fitting-China LG Supply
Forged Steel Ball Eye for Electric Fitting-China LG Supply
Forged Steel Galvanized Joint Hung Plate-LG RIGGING®
Galvanized Insulator Clevis D Iron Bracket-China LG Supply
Galvanized Steel Ball Eye Pole Line Hardware-China LG Supply
Galvanized Thimble Eye Anchor Rod-China LG Supply
Guy Clamp for Pole Line Hardware-China LG Manufacture
High Strength Carbon Steel Galvanized U-Bolts-LG RIGGING®
High Strength Helical Spring Lock Washer-LG RIGGING®
Hot Dip Galvanized Square Curved Cast Washer-LG RIGGING®
Hot Dip Galvanized Steel Clevis Power Fitting-LG RIGGING®
Hot Dip Galvanized Steel Yoke Plate-China LG Supply
Hot-Dip Galvanized Guy Clips-China LG Manufacture
Hot-Dip Galvanized Steel Yoke Plate for Power Line-LG RIGGING®
MF Curved Locknut Square Type-China LG Manufacture
Pole Line Forged Single Thimble Eye Nut-China LG Supply
Pole Line Hardware Forged Ball Eye-China LG Manufacture
Pole Line Hardware Forged Y Type Ball Clevis and Eye-LG RIGGING®
Pole Line Hardware Oval PH Type Chain Link-China LG Supply
Pole Line Hardware Y Type Ball Clevis-China LG Manufacture
Pole Line Hardware ZH Type Chain Link-China LG Supply
Spring Clip Washer Pole Line Fastener-China LG Supply
Square Curved Washer Pole Line Hardware-LG RIGGING®
Square Nut Hot Dip Galvanized-China LG Manufacture
Stainless Steel Round Flat Washer-China LG Manufacture
Steel PT Type Adjustment Plate-China LG Manufacture
Steel Round Pole Band Pole Clamp for Electric Power-LG RIGGING®
Straight Thimble Eye Bolt Pole Line Hardware-LG RIGGING®
Suspension Clamp for Overhead Line-China LG Supply
Tension Clamp for Aluminium Conductor-LG RIGGING®
Tower Pole Step Bolt with Nut-China LG Manufacture
Transformer Bracket Steel Single-Band Component-LG RIGGING®
Triple Eye Anchor Pole Line Hardware-China LG Supply
U Shape Anchor Shackle Pole Line Hardware-LG RIGGING®
U Type Yoke Plate for Line Fitting-China LG Manufacture
Building Components
LGRIG® Lifting Clutch - Concrete Precast Element Lifting

Information of LGRIG® Swageless Stud Terminal Stainless Steel

Brand

LGRIG®

Description

Swageless Stud Terminal/Swageless Thread Terminal

Material

Type 316 Stainless Steel

Processing

Machining

Finish

Highly Polishing

Size - Wire

3mm , 4mm , 5mm , 6mm , 8mm , 10mm , 12mm , 14mm , 16mm

Country of Origin

China


Specifications of LGRIG® Swageless Stud Terminal Stainless Steel


Part No.

Size

M(mm)

L(mm)

L1(mm)

SW1(mm)

SW2(mm)

KG/100

LG-SS-SlF-TS-03

3mm

M6

86

47

10

12

3.5

LG-SS-SlF-TS-04

4mm

M6

92

47

12

14

5

LG-SS-SlF-TS-05

5mm

M8

111

57

14

17

9

LG-SS-SlF-TS-06

6mm

M10

128

63

17

19

14.9

LG-SS-SlF-TS-08

8mm

M12

162

80

19

24

29.5

LG-SS-SlF-TS-10

10mm

M16

190

100

24

27

46

LG-SS-SlF-TS-1216

12mm

M16

–

100

–

30

57

LG-SS-SlF-TS-1220

12mm

M20

227

120

27

32

79

LG-SS-SlF-TS-14

14mm

M22

264

140

30

36

111

LG-SS-SlF-TS-16

16mm

M24

308

170

32

41

163


Please note: we supply a huge variety of stainless steel parts.

We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
Contact LG RIGGING NOW
Contact LG RIGGING
Tel:
+86 19524345486
E-mail:
Add:
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
Request a Free Quote
Upload
or drag files here.

Related Stainless Terminals

LGRIG® Stainless Steel Swageless Eye Terminal
LGRIG® Stainless Steel Swageless Eye Terminal
LGRIG® Stainless Steel Swage Toggle Terminal U.S. Type (thin-wall)
LGRIG® Stainless Steel Swage Toggle Terminal U.S. Type (thin-wall)
LGRIG® Swageless Fork Terminal Stainless Steel
LGRIG® Swageless Fork Terminal Stainless Steel
LGRIG® Stainless Steel Dome Head Terminal
LGRIG® Stainless Steel Dome Head Terminal
LGRIG® Stainless Steel Swage Machined Fork Terminal
LGRIG® Stainless Steel Swage Machined Fork Terminal
LGRIG® Swageless Lag Screw Terminal Stainless Steel
LGRIG® Swageless Lag Screw Terminal Stainless Steel
LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing
LGRIG® Stainless Steel Swage Deck Toggle Terminal for Cable Railing
LGRIG® Swageless Cone Toggle Terminals Stainless Steel
LGRIG® Swageless Cone Toggle Terminals Stainless Steel
China LG RIGGING's Updates
Exhibition in Norway 2024 LG RIGGING®
31
Jul
2025
Exhibition in Norway 2024 LG RIGGING® Learn More
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles
27
Jan
2025
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles Learn More
Introduction to Rigging Turnbuckles: Advantages and Applications
13
Jan
2025
Introduction to Rigging Turnbuckles: Advantages and Applications Learn More
Products
Trawling Gear Lifting & Rigging Stainless Steel Products Boat Fittings Pole Line Hardware Building Components
Resources
Video Blog FAQs About LG RIGGING® Document Download
About
Company News Industry News
Contact Us
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
sales@lg-lifting.com
+86 19524345486
Copyright © QINGDAO LG RIGGING CO.,LTD. All Rights Reserved.
Sitemap | Privacy Policy
sales@lg-lifting.com
+86 19524345486
