Information of LGRIG® DIN444 Eye Swing Bolts Stainless Steel

Brand	LGRIG®
Standard	Eye Swing Bolt Conform to DIN444
Material	Stainless Steel Type 304/316
Processing	Forged and Full Machining
Finish	Highly Polished
Size	M5, M6, M8, M10, M12, M16, M20, M24, M27, M30, M33, M36, M39
Tips	Right handed metric coarse thread.
Country of Origin	China

Specifications of LGRIG® DIN444 Eye Swing Bolts Stainless Steel

Part No.	SIZE	d	P	b			d1		dk				s
Part No.	SIZE	d	Pitch	L≤125	125＜L≤200	L＞200	Max.	Min.	A type Max.	A type Min.,	B&C type Max.	B&C type Min.	A type Max.	A type Min.	B&C type Max.	B&C type Min.
LGSS444M5	M5		0.8	16	/	/	5.03	5	12	10.9	12	11.57	8	7.52	6	5.88
LGSS444M6	M6		1	18	/	/	6.03	6	14	12.9	14	13.57	9	8.52	7	6.85
LGSS444M8	M8		1.25	22	28	/	8.036	8	18	16.9	18	17.57	11	10.3	9	8.85
LGSS444M10	M10		1.5	26	32	/	10.036	10	20	18.7	20	19.48	14	13.3	12	11.82
LGSS444M12	M12		1.75	30	36	49	12.043	12	25	23.7	25	24.48	17	16.3	14	13.82
LGSS444M16	M16		2	38	44	57	16.043	16	32	30.4	32	31.38	19	18.16	17	16.82
LGSS444M20	M20		2.5	46	52	65	18.043	18	40	38.4	40	39.38	24	23.16	22	21.79
LGSS444M24	M24		3	54	60	73	22.052	22	45	43.4	45	44.38	28	27.16	25	24.79
LGSS444M27-1	M27		3	60	66	79	24.052	24	50	48.4	50	49.38	30	29.16	27	26.79
LGSS444M27-2	M27		3	60	66	79	25.052	25	50	48.4	50	49.38	30	29.16	27	26.79
LGSS444M30-1	M30		3.5	66	72	85	27.052	27	55	53.1	55	54.26	34	33	30	29.79
LGSS444M30-2	M30		3.5	66	72	85	28.052	28	55	53.1	55	54.26	34	33	30	29.79
LGSS444M33	(M33)		3.5	/	78	91	30.052	30	60	58.1	60	59.26	38	37	34	33.75
LGSS444M36-1	M36		4	/	84	97	32.062	32	65	63.1	65	64.26	41	40	38	37.75
LGSS444M36-2	M36		4	/	84	97	33.062	33	65	63.1	65	64.26	41	40	38	37.75
LGSS444M39-1	(M39)		4	/	90	103	35.062	35	70	68.1	70	69.26	46	45	41	40.75
LGSS444M39-2	(M39)		4	/	90	103	36.062	36	70	68.1	70	69.26	46	45	41	40.75
