Information of LGRIG® Piling Shackle Long D Shackle

Brand	LGRIG®
Material	High Tensile Steel Grade 4
Shackle Type	Long Dee Shackle
WLL	5: 1
Processing	Forged
Finish	Self-color / Zinc Plated / Hot Dipped Galvanized
Tips	Special specification and marks can be made according to customers’ requirements

Specifications of LGRIG® Piling Shackle Long D Shackle

Part No.	WLL	Diameter Bow	Diameter Pin	Diameter Eye	Width Inside	Length Inside	Weight Each
Part No.	tons	a mm	b mm	c mm	d mm	e mm	kg
LGPS13-16	1	13	16	32	22	152	0.55
LGPS16-19	1.5	16	19	38	32	203	0.95
LGPS19-22	2	19	22	45	38	203	1.64
LGPS22-25	3	22	25	50	45	254	2.29
LGPS25-28	3.75	25	28	57	50	254	3.4
LGPS28-32	5	28	32	64	54	305	5.05
