grade 80 alloy lifting chain EN818-7
grade 80 alloy lifting chain EN818-7

G80 Alloy Lifting Chain EN818-7

G80 alloy lifting Chain are used for lifting.

G80 load trawling chain also can be used as assembly with lifting hook and ring to lift heavy weight.

All chains manufactured to EN818-7 are proof load tested at point of manufacture.

G80 alloy load chains are made from superior alloy steel, heat treatment, are particularly resistant to abrasion.

According to the EN818-7 standard, they are tested to the test load to the tensile tests, and a rigorous dimensional control.

G80 Chain is supplied with test certificates.

Trawling Gear
Shackles
Boat Fittings

Information of G80 Alloy Lifting Chain EN818-7

Technical Notes

Conform To EN818-7

Material

Superior alloy Steel

Processing

Welded

Finish

Powder Coated


Specifications of G80 Alloy Lifting Chain EN818-7

Part No.

Size

NominalT


hickness

Pitch

Width

Weight

Load


Capacity

Load


Capacity

w

p

H

approx

kg*



kg**



mm

mm

mm

kg / m

LG-EN-818-7-01

K3,0x9,0

3,0

9,0

10,4

0,21

140

LG-EN-818-7-02

K4,0x12,0

4,0

12,0

13,7

0,35

400

500

LG-EN-818-7-03

K5,0x15,0

5,0

15,0

16,9

0,54

630

750

LG-EN-818-7-04

K5,6×17,0

5,6

17,0

18,9

0,68

800

1000

LG-EN-818-7-05

K6,0x18,0

6,0

18,0

20,2

0,80

900

1120

LG-EN-818-7-06

K6,0x18,5

6,0

18,5

20,2

0,80

900

1120

LG-EN-818-7-07

K6,3×19,0

6,3

19,0

21,4

0,86

1000

1200

LG-EN-818-7-08

K6,3×19,1

6,3

19,1

21,4

0,86

1000

1200

LG-EN-818-7-09

K6,5×18,5

6,5

18,5

21,8

0,94

1100

1300

LG-EN-818-7-10

K6,5×19,5

6,5

19,5

21,8

0,92

1100

1300

LG-EN-818-7-11

K7,0x21,0

7,0

21,0

23,6

1,10

1250

1500

LG-EN-818-7-12

K7,0x22,0

7,0

22,0

23,6

1,10

1250

1500

LG-EN-818-7-13

K7,1×20,2

7,1

20,2

23,6

1,10

1250

1500

LG-EN-818-7-14

K7,1×21,2

7,1

21,2

23,9

1,10

1250

1500

LG-EN-818-7-15

K7,9×21,8

7,9

21,8

27,0

1,40

1600

2000

LG-EN-818-7-16

K7,9×23,0

7,9

23,0

27,0

1,40

1600

2000

LG-EN-818-7-17

K8,0x22,0

8,0

22,0

27,0

1,40

1600

2000

LG-EN-818-7-18

K8,0x24,0

8,0

24,0

27,0

1,40

1600

2000

LG-EN-818-7-19

K9,0x27,0

9,0

27,0

30,4

1,80

2000

2500

LG-EN-818-7-20

K9,5×25,7

9,5

25,7

31,2

2,00

2240

2800

LG-EN-818-7-21

K9,5×28,6

9,5

28,6

31,2

1,90

2240

2800

LG-EN-818-7-22

K10,0x28,0

10,0

28,0

34,0

2,20

2500

3200

LG-EN-818-7-23

K10,0x30,0

10,0

30,0

34,0

2,20

2500

3200

LG-EN-818-7-24

K11,0x31,0

11,0

31,0

37,4

2,70

3000

3750

LG-EN-818-7-25

K11,2×34,0

11,2

34,0

38,0

2,70

3150

4000

LG-EN-818-7-26

K11,5×33,0

11,5

33,0

38,9

2,90

3150

4000

LG-EN-818-7-27

K13,0x36,0

13,0

36,0

44,2

3,80

4250

5300

LG-EN-818-7-28

K16,0x45,0

16,0

45,0

54,4

5,70

6300

8000

LG-EN-818-7-29

K22,0x66,0

22,0

66,0

75,0

10,70

12500

16000

* motoric hoisting devices
** hand hoisting devices
