4 Inch Ratchet Strap w/ Wire Hooks-LG RIGGING®

Heavy duty ratchet strap offers the extreme strength of a 4'' wide tie down in a shorter.

Wire J-hooks have a zinc finish; great for use with tie down anchor points that may be more narrow or shallow.

The wide-handled ratchet offers a comfortable grip and also has a zinc finish to withstand corrosion.

J-type hook end fittings are made of double wire to increase strength.

Suitable for semi-trailer, trailer, flat bed, rail car, ship and other heavy rope binding applications.

Trawling Gear
Boat Fittings

Information of 4 Inch Ratchet Strap w/ Wire Hooks-China LG™

Size(Inch)

4″

Working Load Limit

5400LBS

Ratchet Handle/Hook

AL Hook/Wire Hook

Ratchet/Hook Color

Yellow Zinc Plated

Webbing Material

Polyester


ISpecifications of 4 Inch Ratchet Strap w/ Wire Hooks-China LG™

Part No.

Size(inch)

B.S.(kg/bs)

A(mm)

B(mm)

C(mm)

LGRH1001

4”

10000KG/22000LBS

*

*

*

LGRH7501

3”

10000KG/22000LBS

130

76

17

LGRH5001

2”

5000KG/11000LBS

105

52

12

LGRH5002

2”

5000KG/11000LBS

115

52

12

LGRH5003

2”

5000KG/11000LBS

85

52

15

LGRH5004

2”

3000KG/6600LBS

85

52

12

LGRH5005

2”

5000KG/11000LBS

130

52

12

LGRH5006

2”

3000KG/6600LBS

85

52

12

LGRH5007

2”

5000KG/11000LBS

106

52

12

LGRH5008

2”

400KG/11000LBS

85

52

11.5

LGRH3501

1.5”

3000KG/6600LBS

65

39

9

LGRH3502

1.5”

3000KG/6600LBS

86

39

9

LGRH3503

1.5”

3000KG/6600LBS

100

35

10

LGRH3504

1.5”

3000KG/6600LBS

65

39

9

LGRH3505

1.5”

2000KG/4400LBS

51

35

7

LGRH3506

1.5”

2000KG/4400LBS

82

32

7

LGRH2501

1  1/16

1500KG/3300LBS

53

27

7

LGRH2502

1  1/16

1500KG/3300LBS

85

27

7

LGRH2503

1  1/16

1500KG/3300LBS

60

27

7

LGRH2504

1”

1000KG/2200LBS

47

27

6.5

LGRH2505

1”

800KG/1760LBS

35

27

6.5

LGRH2506

1”

680KG/1500LBS

47

28

6.5

LGRH2507

1”

800KG/1760LBS

47

28

6


Cautions


  1. Use only not damaged tensioning device, tags can clearly show that ability.

  2. Can’t use overload.

  3. Do not use ribbon knot.

  4. When used, please try to make the fabric away from sharp edges, from wear or cutting.

  5. Avoid twist and the ground layout tensioning device.

  6. Do not place objects on the tensioning device, so as not to cause damage.

  7. Don’t put the tensioning device used as load lifting adjustment.
