K2 Heavy Duty Stub-End Thimble LG RIGGING®, conform to type K2, made from super mild steel.
Heavy duty wire rope thimble K2 offer superior resistance to corrosive elements over standard zinc-plated components so they'll ideal for outdoor applications such as guy wire, tensioning, and other critical, heavy duty jobs.
While zinc-plating offers light resistance, the hot dip process creates a coating that's several times thicker and therefore more rugged than than lighter-duty styles.
Thimble Dimensions:
Thimble sizing must ensure precise alignment between the wire rope and the thimble groove to guarantee optimal load distribution.
Clip Placement Protocol:
First Clip: Position one bridge width from the folded-back rope tail (dead end).
Second Clip: Install directly adjacent to the thimble, ensuring tightening torque does not compromise the rope's outer wires.
Subsequent Clips: Space clips evenly between the first and second clips, maintaining an interval of 1.5× to 3× the clip width (measured center-to-center).
Critical Notes:
Avoid over-tightening clamps to prevent wire abrasion.
| Brand | LGRIG® |
Standard | Type K2 |
Material | Super Mild Steel |
Finish | Hot Dipped Galvanized / Electric Galvanized |
Size | 2", 2-1/2", 3", 3-1/2", 4", 4-1/2", 5", 5-1/2", 6", ", 8", 9", 10", 11", 12", 14", 17", 19", 22", 24", 26" |
Tips | With or without reinforcing plate, as per customer's requirement. |
Note | NOT FOR LIFTING PURPOSES |
| Country of Origin | China |

Part No. | A | B | C | D | E | F | Weight |
LGTK22 | 2″ | 42 | 35 | 22 | 9 | 14 | 8.2 |
LGTK22-1/2 | 2-1/2″ | 50 | 45 | 30 | 11 | 16 | 10 |
LGTK23 | 3″ | 50 | 55 | 35 | 13 | 18 | 20 |
LGTK23-1/2 | 3-1/2″ | 73 | 65 | 45 | 15 | 20 | 26 |
LGTK24 | 4″ | 75 | 75 | 50 | 17 | 22 | 36 |
LGTK24-1/2 | 4-1/2″ | 85 | 80 | 53 | 19 | 25 | 50 |
LGTK25 | 5″ | 100 | 90 | 60 | 21 | 29 | 60 |
LGTK25-1/2 | 5-1/2″ | 110 | 95 | 65 | 23 | 33 | 70 |
LGTK26 | 6″ | 115 | 120 | 70 | 25 | 34 | 100 |
LGTK27 | 7″ | 135 | 140 | 80 | 30 | 38 | 160 |
LGTK28 | 8″ | 155 | 160 | 100 | 33 | 44 | 180 |
LGTK29 | 9″ | 175 | 185 | 115 | 38 | 49 | 350 |
LGTK210 | 10″ | 190 | 195 | 120 | 41 | 52 | 440 |
LGTK211 | 11″ | 210 | 215 | 130 | 46 | 60 | 520 |
LGTK212 | 12″ | 245 | 250 | 145 | 52 | 65 | 730 |
LGTK214 | 14″ | 260 | 290 | 155 | 60 | 72 | 1100 |
LGTK217 | 17″ | 310 | 370 | 190 | 70 | 84 | 1600 |
LGTK219 | 19″ | 350 | 420 | 230 | 81 | 119 | 2750 |
LGTK222 | 22″ | 395 | 480 | 255 | 92 | 130 | 3650 |
LGTK224 | 24″ | 430 | 540 | 280 | 105 | 145 | 4400 |
LGTK226 | 26″ | 450 | 580 | 285 | 120 | 155 | 4700 |
Galvanized rope thimbles are designed for heavy duty jobs. If you need a light duty style, or a stainless steel fabrication, check out our other styles of thimbles for wire rope:
G-411 Standard Duty Galvanized Wire Rope Thimble.
