G80 Viking Link Alloy Steel

Viking Links High Tensile Steel Forged, quenched and tempered, to fit recessed link. It also called viking split links or DV viking links.

Size: 8LGDV15,8LGDV30,8LGDV50,8LGDV80.

G80 Viking Hook also known as G80 DV hook or G80 viking G hook, forged from superior alloy steel with high strength and high toughness,heat treated.

Grade 80 viking g hooks can be used with slings and G80 chains to meet EN818-2 standards;

Each workpiece should pass testing at 2.5 times of working load limit;

We should carry out sampling and 20000 times of fatigue testing;

We should carry out strict sampling and breakage testing for each batch of products;

100% of the pin should be tested to ensure that they have the same hardness.

Trawling Gear
Shackles
Boat Fittings

Information of G80 Viking Link Alloy Steel

Technical Notes

European Type

Material

Alloy Steel

Δ Note

Ultimate load is 4 times the Working Load Limit

Processing

Forged / Quenched and Tempered.

Finish

Powder Coated

WLL

1.5T, 3T, 5T, 8T

Tips

Color Code: Customized according to customers’ requirements


Specifications of G80 Viking Link Alloy Steel

Specifications of G80 Viking Hook Alloy Steel


Part No.

Weight (kg)

Working Load Limit/t

Breaking Load/t

N±1

B±1.5

E±0.1

H±1

L±1.2

8LGDV15

0.5

1.5

7.5

28

61

3

35

102

8LGDV30

0.73

3

15

30

72

3

41

119

8LGDV50

1.2

5

25

35

84.5

3

42

137

8LGDV80

1.6

8

40

42

96

3

42

153


Bulk Photos of G80 Viking Link Alloy Steel

viking split link high tensile steel WLL1.5Ton
viking link high tensile steel WLL3Ton
viking split link high tensile steelDV50
viking split link high tensile steel DV type DV80
