 Trawling Shackle D Type Blue Painted Square Head Pin of Lifting & Rigging Shackles

 Trawling Shackle Bow Type Square Head Pin Blue Painted of Lifting & Rigging Shackles

 Bow Shackle Square Head Pin High Tensile of Lifting & Rigging Shackles

 Dee Shackle Square Head Pin for Lifting and Rigging Shackles

 Bow Shackle Sunken Head of Lifting & Rigging Shackles

 Dee Shackle Sunken Head of Lifting & Rigging Shackles

 LGRIG® G80 Unilock Shackle Connecting Link

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Grade 80 Alloy Screw Pin Anchor Shackle

Brand	LGRIG®
Grade	Grade 8
Technical Notes	Meets or exceeds all requirements of ASME B30.26, Federal Specification RR-C-271, & ASTM A148M.
Material	Superior Alloy Steel
Model	G-209A
Shackle Type	Anchor Shackle / Bow Shackle
Pin Type	Screw Pin
Processing	Drop Forged / Quenched and Tempered
Safety Factor	5: 1
Finish	Body: Hot Dipped Galvanized Pin: Powder Coating
Size	5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4”, 7/8”, 1” 1-1/8”, 1-1/4”, 1-3/8”, 1-1/2”, 1-3/4”, 2”
WLL	1.2Ton, 1.6Ton, 2.5Ton, 3.3Ton, 5Ton, 7Ton, 9.5Ton, 12.5Ton, 15Ton, 18Ton, 21Ton, 30Ton, 40Ton, 55Ton
Tips	Special specification and marks can be made according to customers’ requirements

Specifications of LGRIG® Grade 80 Alloy Screw Pin Anchor Shackle

Part No.	Size	Weight/Lbs	Wll/t	B.l/t	A±1.5	C±1.5	D±1	N	L±3
8LGASSP5/16	5/16″	0.19	1.2	6	13.5	21.3	8	9.5	53
8LGASSP3/8	3/8″	0.31	1.6	8	16.8	25.9	9.7	11	63.2
8LGASSP7/16	7/16″	0.38	2.5	12.5	19	29.5	11.2	13	74
8LGASSP1/2	1/2″	0.73	3.3	16.5	20.6	33.3	12.7	16	83.3
8LGASSP5/8	5/8″	1.37	5	25	27	42.9	17.5	19	106.4
8LGASSP3/4	3/4″	2.36	7	35	32	20.8	20.6	22	126.2
8LGASSP7/8	7/8″	3.62	9.5	47.5	36.6	57.9	24.6	25	148
8LGASSP1/1	1″	5.03	12.5	62.5	43	68.3	27	28	166.6
8LGASSP1-1/8	1-1/8″	7.41	15	75	46	74	31.75	32	190
8LGASSP1-1/4	1-1/4″	9.5	18	90	51.6	82.5	35	35	210
8LGASSP1-3/8	1-3/8″	13.53	21	105	57	92	36	38	232.7
8LGASSP1-1/2	1-1/2″	17.2	30	150	60.5	98	41	42	254
8LGASSP1-3/4	1-3/4″	27.78	40	200	73.2	126	57.2	51	313.7
8LGASSP2/1	2″	45	55	275	82.5	146	61	57	347.5
