Dee Shackle Square Head Pin For Trawling

Our Dee Shackle Square Head Pin For Trawling also known as chain shackle with square head pin.


D shackle square head pin for trawling is manufactured to the highest standards.


These trawling D shackles with square head pin are commonly used in the marine industry for trawling purposes during fishing expeditions.


The trawling D shackle with square head pin, made from high tensile steel, Grade 6, quenched and tempered.


Safety factor of square head pin Dee shackle is MBL equals 6 x WLL


The standard of trawl D shackle with square head pin is EN 13889 and meets performance requirements of US Fed. Spec. RR-C-271, Grade A


Our range of trawling shackle is available in standard as well as customized sizes.

Trawling Gear
Shackles
Boat Fittings

Information of Dee Shackle Square Head Pin For Trawling

Technical Notes

U.S. Federal Specification

Safety Factor

6:1

Material

Body:45# Steel, Screw Pin: Alloy Steel.

Processing

Forged / Quenched and Tempered.

Finish

Self- colored / Zinc plated, Hot dipped galvanized.

Size

1/2″,5/8″      3/4″     7/8″     1″    1 1/8″      1 1/4″    1 3/8″      1 1/2″

Tips

according to customers’ requirements we can made Special specification and marks


Specifications of Dee Shackle Square Head Pin For Trawling

Specifications of Dee Shackle Square Head Pin For Trawling


Part No.

Size

WLL

d


(mm)

D


(mm)

a


(mm)

C


(mm)

weight

in

mm

ton

kg/piece

LG-DS-SH12

1/2″

12.7

2

16

13

22

43

0.34

LG-DS-SH58

5/8″

16

3.25

19

16

27

51

0.63

LG-DS-SH34

3/4″

19

4.75

22

19

31

59

0.95

LG-DS-SH78

7/8″

22

6.5

25

22

36

73

1.55

LG-DS-SH01

1″

25

8.5

28

25

43

85

2.3

LG-DS-SH118

1 1/8″

28

9.5

32

28

47

90

3.24

LG-DS-SH114

1 1/4″

32

12

35

32

51

94

4.4

LG-DS-SH138

1 3/8″

35

13.5

38

35

57

115

6

LG-DS-SH112

1 1/2″

38

17

42

38

60

127

8


Bulk Photos of Dee Shackle Square Head Pin For Trawling

bulk photos of dee shackle square head pin for trawling
bulk photos of dee shackle square head pin for trawling 2
bulk photos of dee shackle square head pin for trawling 3
bulk photos of dee shackle square head pin for trawling 4
bulk photos of dee shackle square head pin for trawling 5
We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
