 Steel Spacers with Chain with Ring LG RIGGING®

 Steel Spacers Heavy Duty EDT Welded LG RIGGING®

 Chain Toggles Heavy Type Welded Steel LG RIGGING®

 Chain Toggles for Chain for Fish Trawl Foot-rope LG RIGGING®

 Wire Toggle for Fish Trawl Foot-rope LG RIGGING®

 Stainless Steel Wire Toggles YOYO LG RIGGING®

Safety Appliance 

Footrope Gear 

Trawl Door 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of Steel Spacers Heavy Duty EDT Welded LG RIGGING®

Brand	LG RIGGING®
Material	Superior Mild Steel
Processing	Welded
Finish	Self-colored
Size-Chain	EDT16, EDT19, EDT22

Specifications of Steel Spacers Heavy Duty EDT Welded LG RIGGING®

Specifications of Chain Toggles Heavy Type Steel Welded-China LG™

Part No.	A (inner dia.) mm	B mm	C mm	D1 mm	D2 mm	E mm	F mm	G	Weight kg
LGEDT16-075-05MLL13	61	76	428	16	165	10	134	13	3.64
LGEDT16-075-07MLL13	61	76	528	16	165	10	134	13	3.97
LGEDT16-075-10HLL11	61	76	836	16	165	10	134	11	4.15
LGEDT19-100-05MLL13	74	100	428	16	165	14	175	13	7.05
LGEDT19-100-07MLL13	74	100	528	16	165	14	175	13	7.38
LGEDT22-115-10HLL13	80	115	988	19	165	16	180	13	9.50
LGEDT22-115-13HLL13	80	115	1231	19	165	16	180	13	10.16
