D Shackle Oversized Bolt Type Pin Stainless Steel

D Shackle Oversized Bolt Type Pin Stainless Steel, also known as chain shackle, have a large D shaped that allows them to take loads from many directions without developing significant side load. That makes them ideal for use with multiple-leg slings, connecting slings to load rings, and accommodating a wider strap.

This a stainless steel chain shackle, not to be used for overhead lifting. AISI 316 stainless is a premium grade of stainless and is considered by many to be best in class. 316 stainless is corrosion resistant and very durable even in the harshest of conditions.

Stainless steel D shackle oversized pin bolt type US type, marked in the imperial specification style of size (for the bow diameter).

This D shackle is free forging and made in the US Type style of an oversized castle nut and cotter pin. The bow diameter dictates the size of this US type anchor shackle, so this chain shackle has an oversized cotter bolt pin.

The oversized pin bolt configuration is best for use in applications that are temporary, or require repeated or quick connections and disconnections.

G-2150 Stainless Steel Chain Shackle cotter bolt oversized meets the performance requirements of Federal Specification RR-C-271F Type IVB, Grade A, Class 3.

Working Load Limit permanently shown on every shackle.

Get A Quote
Products
Trawling Gear
Fishing Net Float & Buoy
Trawling Swivel
Trawling Shackle
Grade80 / Grade100
Rope Thimbles
Rope Splicing Spike
Hooks / Links / Rope Fittings
Trawling Chain
Lifting Sling
Trawl Block
Wire / Chain Toggles
Anchors & Fittings
Dock Products
Safety Appliance
Lifting & Rigging
G100 Products
G80 Products
Turnbuckles
Shackles
Eye Bolts & Nuts
Rigging Hooks
Swivels
Forged Rings & Connector
Quick Links
Snap Hooks
Wire Rope
Wire Rope Thimbles
Wire Ropes Clips & Grips
Wire Rope Sleeves/Ferrules
Chains & Accessories
Chain Binders
Ratchet Straps
Lifting Sling of Lifting & Rigging
Lever Hoist
Pulley & Blocks
Lifting & Rigging Pins
Forestry Logging Supplies
Eye Plate
Stainless Steel Products
Shade Sail Hardware
Stainless Shackles
Bow Shackle Stainless Steel Screw Pin European Type for Stainless Shackles
Stainless Steel D Shackle Screw Pin European Type
Stainless Steel Anchor Shackle Oversized Screw Pin
Stainless Steel Chain Shackle Oversized Screw Pin
Stainless Steel Bow Shackle Oversized Bolt Type Pin
D Shackle Oversized Bolt Type Pin Stainless Steel
Bow Shackle Stainless Steel Square Head Pin for Stainless Shackles
D Shackle Stainless Steel Square Head Pin for Stainless Shackles
Stainless Steel D Shackle Captive Pin
Stainless Steel Jaw Swivel Snap Shackle for Sailboat
Stainless Steel Fixed Bail Snap Shackle
Stainless Steel Eye Swivel Snap Shackle for Sailboat
Stainelss Steel D Shackle, JIS Type
Stainless Turnbuckle
Stainless Eye Bolts & Nuts
Stainless Thimbles
Stainless Rings
Stainless Swivels
Stainless Quick Link
Stainless Wire Clips
Stainless Hooks & Clips
Stainless Terminals
Stainless U Bolts
Stainless Hinge
Stainless Pulleys
Drop Forged Stainless Products
Stainless Chains
Eye Plate, Eye Straps, Angles
Boat Fittings
Stainless Marine Hinges
Bimini Top Fittings
Cleats & Fairleads
Angle Bracket
Rail Fittings
Thru-Hull & Deck Fittings
Stainless Latches
Pole Line Hardware
A-Cable Suspension Bolt-China LG Manufacture
Adjusting Plate for Power Line-China LG Manufacture
Angle Eye Bolt Pole Line Hardware-China LG Supply
Cable Span Clamps Pole Line Hardware-China LG Manufacture
Carriage Bolts For Overhead Line Construction-China LG Supply
Crossover Clamp-China LG Manufacture
Electric Power Bow/Dee Shackle for Power Line-China LG Supply
Electric Power Eye Shaft Screw Anchor-China LG Supply
Electric Power Socket Clevis WSY-China LG Manufacture
Electric Power Socket Clevis-Double Type-Line Hardware-LG RIGGING®
Electric Power Socket Clevis-Single Type-Line Hardware-China LG Supply
Electric Power Thimble Eye Nut-China LG Manufacture
Electric Power U Ball Clevis-China LG Manufacture
Electrical Wire Cable Thimble Clevis-China LG Supply
Forged Eye Bolt For Anchor Assemble-China LG Supply
Forged Oval Eye Nut for Pole Line Fitting-China LG Supply
Forged Steel Ball Eye for Electric Fitting-China LG Supply
Forged Steel Galvanized Joint Hung Plate-LG RIGGING®
Galvanized Insulator Clevis D Iron Bracket-China LG Supply
Galvanized Steel Ball Eye Pole Line Hardware-China LG Supply
Galvanized Thimble Eye Anchor Rod-China LG Supply
Guy Clamp for Pole Line Hardware-China LG Manufacture
High Strength Carbon Steel Galvanized U-Bolts-LG RIGGING®
High Strength Helical Spring Lock Washer-LG RIGGING®
Hot Dip Galvanized Square Curved Cast Washer-LG RIGGING®
Hot Dip Galvanized Steel Clevis Power Fitting-LG RIGGING®
Hot Dip Galvanized Steel Yoke Plate-China LG Supply
Hot-Dip Galvanized Guy Clips-China LG Manufacture
Hot-Dip Galvanized Steel Yoke Plate for Power Line-LG RIGGING®
MF Curved Locknut Square Type-China LG Manufacture
Pole Line Forged Single Thimble Eye Nut-China LG Supply
Pole Line Hardware Forged Ball Eye-China LG Manufacture
Pole Line Hardware Forged Y Type Ball Clevis and Eye-LG RIGGING®
Pole Line Hardware Oval PH Type Chain Link-China LG Supply
Pole Line Hardware Y Type Ball Clevis-China LG Manufacture
Pole Line Hardware ZH Type Chain Link-China LG Supply
Spring Clip Washer Pole Line Fastener-China LG Supply
Square Curved Washer Pole Line Hardware-LG RIGGING®
Square Nut Hot Dip Galvanized-China LG Manufacture
Stainless Steel Round Flat Washer-China LG Manufacture
Steel PT Type Adjustment Plate-China LG Manufacture
Steel Round Pole Band Pole Clamp for Electric Power-LG RIGGING®
Straight Thimble Eye Bolt Pole Line Hardware-LG RIGGING®
Suspension Clamp for Overhead Line-China LG Supply
Tension Clamp for Aluminium Conductor-LG RIGGING®
Tower Pole Step Bolt with Nut-China LG Manufacture
Transformer Bracket Steel Single-Band Component-LG RIGGING®
Triple Eye Anchor Pole Line Hardware-China LG Supply
U Shape Anchor Shackle Pole Line Hardware-LG RIGGING®
U Type Yoke Plate for Line Fitting-China LG Manufacture

Information of D Shackle Oversized Bolt Type Pin Stainless Steel

Technical Notes

D shackle conform to U.S. Federal Specification

Material

Stainless steel AISI 304/316 Chain Shackle

Processing

Free Forging

Finish

Highly Polishing / Electrophoretic coating

Size

3/16”, 1/4”, 5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4”, 7/8”, 1”, 1-1/8”, 1-1/4”


Specifications of D Shackle Oversized Bolt Type Pin Stainless Steel G-2150

Specifications of D Shackle Oversized Bolt Type Pin Stainless Steel G-2150


Part No.

A


Size

B


Pin dia

C

D

Min.BL

in

KN

LG-SS-2150-S-3/16

3/16

1/4

0.38

0.71

13.7

LG-SS-2150-S-1/4

1/4

5/16

0.47

0.88

24.4

LG-SS-2150-S-5/16

5/16

3/8

0.53

1.03

38.2

LG-SS-2150-S-3/8

3/8

7/16

0.66

1.25

54.9

LG-SS-2150-S-7/16

7/16

1/2

0.75

1.44

54.9

LG-SS-2150-S-1/2

1/2

5/8

0.81

1.63

97.7

LG-SS-2150-S-5/8

5/8

3/4

1.06

2.00

152.6

LG-SS-2150-S-3/4

3/4

7/8

1.25

2.38

184.7

LG-SS-2150-S-7/8

7/8

1

1.44

2.81

219.7

LG-SS-2150-S-1/1

1

1-1/8

1.69

3.19

278.1

LG-SS-2150-S-1-1/8

1-1/8

1-1/4

1.81

3.58

390.7

LG-SS-2150-S-1-1/4

1-1/4

1-3/8

2.03

3.94

494.4


We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
Contact LG RIGGING NOW
Contact LG RIGGING
Tel:
+86-0532-66851176
E-mail:
Add:
A408, Sungwon Foreign Trade Center, No.187 Heilongjiang Middle Road, Chengyang District, Qingdao, China.
Request a Free Quote
Upload
or drag files here.

Related Stainless Shackles

Stainless Steel Chain Shackle Oversized Screw Pin
Stainless Steel Chain Shackle Oversized Screw Pin
Stainless Steel D Shackle Screw Pin European Type
Stainless Steel D Shackle Screw Pin European Type
D Shackle Stainless Steel Square Head Pin for Stainless Shackles
D Shackle Stainless Steel Square Head Pin for Stainless Shackles
Stainless Steel Anchor Shackle Oversized Screw Pin
Stainless Steel Anchor Shackle Oversized Screw Pin
Stainless Steel Bow Shackle Oversized Bolt Type Pin
Stainless Steel Bow Shackle Oversized Bolt Type Pin
Stainless Steel Fixed Bail Snap Shackle
Stainless Steel Fixed Bail Snap Shackle
Stainless Steel Eye Swivel Snap Shackle for Sailboat
Stainless Steel Eye Swivel Snap Shackle for Sailboat
Stainless Steel D Shackle Captive Pin
Stainless Steel D Shackle Captive Pin
China LG RIGGING's Updates
Galvanized Vs. Stainless Steel Rope Thimbles: A Comparative Study
18
Apr
2024
Galvanized Vs. Stainless Steel Rope Thimbles: A Comparative Study Learn More
How to Properly Use a Rope Thimble: a Step-by-Step Guide
11
Apr
2024
How to Properly Use a Rope Thimble: a Step-by-Step Guide Learn More
The Role of Wire Thimble Types in Stage Rigging
04
Apr
2024
The Role of Wire Thimble Types in Stage Rigging Learn More
Products
Trawling Gear Lifting & Rigging Stainless Steel Products Boat Fittings Pole Line Hardware
Resources
FAQs About LG RIGGING® Document Download Blog
About
Company News Industry News
Contact Us
A408, Sungwon Foreign Trade Center, No.187 Heilongjiang Middle Road, Chengyang District, Qingdao, China.
sales@lg-lifting.com
+86-0532-66851176
Copyright © QINGDAO LG RIGGING CO.,LTD. All Rights Reserved.
Sitemap | Privacy Policy
sales@lg-lifting.com
+86-0532-66851176
