LGRIG® Stainless Steel Double Barrel Crimping Loop Sleeve

Name: LGRIG® Stainless Steel Double Barrel Crimping Loop Sleeve
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

LGRIG® Stainless Steel Double Barrel Crimping Loop Sleeve, also called Stainless Steel Hourglass Sleeves, double barrel crimping ferrules.

Stainless Steel Double Barrel Crimping Loop Sleeve is ideal for use with stainless steel wire rope and cable, easily hand crimped for stainless wire balustrading with a burr-free profile that prevents fraying of wires during insertion.

Stainless Steel Hourglass Sleeves are made from Type 304 or Type 316 Stainless Steel with a highly polished finish for added corrosion resistance, and unlike aluminium ferrules, they will not promote galvanic corrosion when used with stainless wire rope.

Double barrel crimping ferrules are used to create loop ends on cable assemblies or to attach two assemblies together, featuring an hourglass duplex shape that allows for the smoothest swage and crimp.

These Stainless Steel Ferrules are extruded and heat treated for the best cold-forming properties, and the sleeve size must match the cable diameter for proper installation using an appropriate swaging tool.

The Stainless Steel Double Barrel Crimping Loop Sleeve features a double barrel design that ensures a secure and reliable connection, is simple and easy to use, and offers corrosion and rust resistance for a secure connection every time.

Stainless Steel Hourglass Sleeves are hand swages also known as crimps or ferrules, designed to work with high and medium flexibility stainless steel wire rope, with each size specifically matched to a particular wire diameter.

Double barrel crimping ferrules used to link two strands of wire together are called duplex swages, and hourglass swages are viewed as hand swages requiring only a mechanical tool rather than a hydraulic press.

These Stainless Steel Ferrules are typically used with thimbles so that when secured, the force of the bearing point is evenly distributed along the thimble, minimizing wear and stretch on the wire cable for a professional and durable termination.

Get A Quote

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

 LGRIG® Cable Ferrule Aluminium DIN 3093(EN 13411-3) of Wire Rope Sleeves Ferrules

 LGRIG® Cable Ferrule Stainless Steel DIN 3093(EN 13411-3)

 LGRIG® Wire Rope Ferrule Aluminium Oval Shape

 LGRIG® Wire Rope Sleeve Double Barrel Ferrule

 LGRIG® Wire Rope Ferrule JIS Type

 LGRIG® Wire Rope Ferrule Form C DIN 3093

 LGRIG® Wire Rope Ferrule Copper Hourglass Ferrules

 LGRIG® Copper Button Stop Round Ferrule

 LGRIG® Swage Sleeve Flemish Eye Steel S505

 LGRIG® Swage Duplex Sleeves Steel S-506

 LGRIG® Wire Rope End Stop Steel LGS-409

 LGRIG® Aluminium Button Stop Round Ferrules

 LGRIG® Copper Ferrule Oval Type Z

 LGRIG® Stainless Steel Double Barrel Crimping Loop Sleeve

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Stainless Steel Double Barrel Crimping Loop Sleeve

Brand	LGRIG®
Material	Type 304 or Type 316 Stainless Steel
Style	Double Barrel Crimping Loop Sleeve/Hourglass Sleeves
Processing	Machining + Extruded
Size	1mm, 1.5mm, 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 6mm, 6.5mm, 7mm , 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 16mm, 18mm, 20mm, 22mm, 24mm, 26mm, 28mm, 30mm, 32mm, 34mm, 36mm, 38mm, 40mm, 42mm, 44mm, 46mm, 48mm, 50mm, 52mm, 54mm, 56mm, 58mm, 60mm
Country of Origin	China
