LGRIG®-stainless-steel-angled-exhaust-skin-fitting
LGRIG®-stainless-steel-angled-exhaust-skin-fitting

LGRIG® Stainless Steel Angled Exhaust Skin Fitting

The LGRIG® Stainless Steel Angled Exhaust Skin Fitting is designed to provide a practical and secure through-hull exhaust connection for marine diesel heaters and other compatible heating systems. Featuring an angled, raked outlet design, this stainless steel exhaust skin fitting helps guide the exhaust pipe in a suitable direction after passing through the hull or mounting surface.

The angled configuration is particularly useful where installation space or exhaust routing requires a downward or offset pipe direction.

Constructed from stainless steel, the fitting provides durable performance and good resistance to corrosion in demanding marine environments, while the polished exterior offers a clean and professional appearance.

The wide mounting flange and gasket interface help create a stable installation when correctly fitted, while the three mounting screws provide secure attachment to the hull or bulkhead.

Available in 22 mm and 24 mm sizes, this angled thru-hull exhaust fitting is suitable for compatible diesel heater exhaust pipes used with marine heaters, parking heaters and other vehicle or vessel heating systems.

It can be used for new installations, heater upgrades, maintenance and replacement projects. Combining stainless steel construction, an angled exhaust outlet and a compact skin fitting design, this raked exhaust skin fitting provides a practical solution for routing heater exhaust safely through a suitable hull or mounting surface.

Get A Quote
Products
Trawling Gear
Trawling Swivel
Hooks
Trawling Shackle
Rope Thimbles
Rings & Links
Kelly's Eye & Stoppers
G-Hooks & Recessed Links
Connectors
Tools
Rockhopper Spare Parts
Trawling Chain
Synthetic Rope
Trawl Wire
Anchors & Fittings
Wire Rope Clips
Ferrules & Terminals
Rigging Screws
Fishing Net Float
Fenders & Buoys
Lashing/Slings/Load Binders
Trawl Blocks & Pulley
Toggles & Spacers
Safety Appliance
Footrope Gear
Trawl Door
Lifting & Rigging
G100 Products
G80 Products
Turnbuckles
Shackles
Eye Bolts & Nuts
Rigging Hooks
Swivels
Forged Rings & Connector
Quick Links
Snap Hooks
Wire Rope
Wire Rope Thimbles
Wire Ropes Clips & Grips
Wire Rope Sleeves/Ferrules
Chains & Accessories
Chain Binders
Ratchet Straps
Lifting Sling of Lifting & Rigging
Lever Hoist
Pulley & Blocks
Lifting & Rigging Pins
Forestry Logging Supplies
Eye Plate
Stainless Steel Products
Shade Sail Hardware
Stainless Shackles
Stainless Turnbuckle
Stainless Eye Bolts & Nuts
Stainless Thimbles
Stainless Rings
Stainless Swivels
Stainless Quick Link
Stainless Wire Clips
Stainless Hooks & Clips
Stainless Terminals
Stainless Chains
Stainless U Bolts
Stainless Hinge
Stainless Pulleys
Drop Forged Stainless Products
Eye Plate, Eye Straps, Angles
Boat Fittings
Stainless Marine Hinges
Bimini Top Fittings
Cleats & Fairleads
Angle Bracket
Rail Fittings
Thru-Hull & Deck Fittings
Stainless Steel Low Profile Thru Hull Fitting Hose Connection-China
Stainless Steel Tank Vent 90 Degree-China LG Supply
Stainless Steel Deck Fill 45 Degree-LG RIGGING®
Stainless Steel Deck Filler-China LG Manufacture
LGRIG® Stainless Steel Marine Deck Fill with Key
LGRIG® 316 Stainless Steel Deck Fill with Keyless Cap
LGRIG® 316 Stainless Steel 45°Angled Deck Fill with Key
LGRIG® 316 Stainless Steel 45°Angled Keyless Deck Fill
LGRIG® Nylon Fuel Deck Fill with Keyless Cap
LGRIG® Nylon Deck Fill with Keyless Cap –Water
LGRIG® Nylon Thru-Hull Fitting with Hose Barb - Skin Fitting
LGRIG® Nylon Straight Thru-hull fitting with Stainless Steel Trim
LGRIG® Stainless Steel Marine Deck Drain Scupper
LGRIG® Stainless Steel Straight Thru-Hull Exhaust Skin Fitting
LGRIG® Stainless Steel Angled Exhaust Skin Fitting
Stainless Latches
Mooring Compensators / Springs
Brake Lining
Pole Line Hardware
A-Cable Suspension Bolt-China LG Manufacture
Adjusting Plate for Power Line-China LG Manufacture
Angle Eye Bolt Pole Line Hardware-China LG Supply
Cable Span Clamps Pole Line Hardware-China LG Manufacture
Carriage Bolts For Overhead Line Construction-China LG Supply
Crossover Clamp-China LG Manufacture
Electric Power Bow/Dee Shackle for Power Line-China LG Supply
Electric Power Eye Shaft Screw Anchor-China LG Supply
Electric Power Socket Clevis WSY-China LG Manufacture
Electric Power Socket Clevis-Double Type-Line Hardware-LG RIGGING®
Electric Power Socket Clevis-Single Type-Line Hardware-China LG Supply
Electric Power Thimble Eye Nut-China LG Manufacture
Electric Power U Ball Clevis-China LG Manufacture
Electrical Wire Cable Thimble Clevis-China LG Supply
Forged Eye Bolt For Anchor Assemble-China LG Supply
Forged Oval Eye Nut for Pole Line Fitting-China LG Supply
Forged Steel Ball Eye for Electric Fitting-China LG Supply
Forged Steel Galvanized Joint Hung Plate-LG RIGGING®
Galvanized Insulator Clevis D Iron Bracket-China LG Supply
Galvanized Steel Ball Eye Pole Line Hardware-China LG Supply
Galvanized Thimble Eye Anchor Rod-China LG Supply
Guy Clamp for Pole Line Hardware-China LG Manufacture
High Strength Carbon Steel Galvanized U-Bolts-LG RIGGING®
High Strength Helical Spring Lock Washer-LG RIGGING®
Hot Dip Galvanized Square Curved Cast Washer-LG RIGGING®
Hot Dip Galvanized Steel Clevis Power Fitting-LG RIGGING®
Hot Dip Galvanized Steel Yoke Plate-China LG Supply
Hot-Dip Galvanized Guy Clips-China LG Manufacture
Hot-Dip Galvanized Steel Yoke Plate for Power Line-LG RIGGING®
MF Curved Locknut Square Type-China LG Manufacture
Pole Line Forged Single Thimble Eye Nut-China LG Supply
Pole Line Hardware Forged Ball Eye-China LG Manufacture
Pole Line Hardware Forged Y Type Ball Clevis and Eye-LG RIGGING®
Pole Line Hardware Oval PH Type Chain Link-China LG Supply
Pole Line Hardware Y Type Ball Clevis-China LG Manufacture
Pole Line Hardware ZH Type Chain Link-China LG Supply
Spring Clip Washer Pole Line Fastener-China LG Supply
Square Curved Washer Pole Line Hardware-LG RIGGING®
Square Nut Hot Dip Galvanized-China LG Manufacture
Stainless Steel Round Flat Washer-China LG Manufacture
Steel PT Type Adjustment Plate-China LG Manufacture
Steel Round Pole Band Pole Clamp for Electric Power-LG RIGGING®
Straight Thimble Eye Bolt Pole Line Hardware-LG RIGGING®
Suspension Clamp for Overhead Line-China LG Supply
Tension Clamp for Aluminium Conductor-LG RIGGING®
Tower Pole Step Bolt with Nut-China LG Manufacture
Transformer Bracket Steel Single-Band Component-LG RIGGING®
Triple Eye Anchor Pole Line Hardware-China LG Supply
U Shape Anchor Shackle Pole Line Hardware-LG RIGGING®
U Type Yoke Plate for Line Fitting-China LG Manufacture
Building Components
LGRIG® Lifting Clutch - Concrete Precast Element Lifting

Information of LGRIG® Stainless Steel Angled Exhaust Skin Fitting

Brand

LGRIG®

Product Name

Stainless Steel Angled Exhaust Skin Fitting

Alternative Name

Stainless Steel Angled Thru-Hull Exhaust Fitting

Product Type

Angled / Raked Exhaust Skin Fitting

Material

Stainless Steel

Surface

Polished / Smooth Finish

Configuration

Angled / Raked

Connection Type

Exhaust Pipe / Tube Connection

Installation Type

Through-Hull

Available Sizes

22 mm / 24 mm

Mounting

3-Screw Flange Mounting

Features

Durable, Corrosion Resistant, Angled Outlet, Compact Design, Easy Installation

Use

Exhaust Pipe Connection / Through-Hull Exhaust

Applications

Diesel Heater Exhaust, Marine Heater Exhaust, Parking Heater Exhaust

Suitable For

Boats, Yachts, Marine Heaters and Compatible Heating Systems

Country of Origin

China


Specification of LGRIG® Stainless Steel Angled Exhaust Skin Fitting


Part No.

SIZE

A (mm)

B (mm)

C (mm)

D (mm)

E (mm)

F (mm)

N.W. (KG)

G.W. (KG)

LGSSTHE45A22

22 mm

80.0

107.0

54.0

39.0

5.5

22.0

0.413

0.445

LGSSTHE45A24

24 mm

80.0

109.0

54.0

39.0

5.5

24.0

0.425

0.455


We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
Contact LG RIGGING NOW
Contact LG RIGGING
Tel:
+86 19524345486
E-mail:
Add:
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
Request a Free Quote
Upload
or drag files here.

Related Thru-Hull & Deck Fittings

LGRIG® 316 Stainless Steel 45°Angled Keyless Deck Fill
LGRIG® 316 Stainless Steel 45°Angled Keyless Deck Fill
LGRIG® 316 Stainless Steel Deck Fill with Keyless Cap
LGRIG® 316 Stainless Steel Deck Fill with Keyless Cap
LGRIG® Nylon Straight Thru-hull fitting with Stainless Steel Trim
LGRIG® Nylon Straight Thru-hull fitting with Stainless Steel Trim
Stainless Steel Deck Fill 45 Degree-LG RIGGING®
Stainless Steel Deck Fill 45 Degree-LG RIGGING®
LGRIG® Stainless Steel Straight Thru-Hull Exhaust Skin Fitting
LGRIG® Stainless Steel Straight Thru-Hull Exhaust Skin Fitting
Stainless Steel Low Profile Thru Hull Fitting Hose Connection-China
Stainless Steel Low Profile Thru Hull Fitting Hose Connection-China
LGRIG® Stainless Steel Marine Deck Fill with Key
LGRIG® Stainless Steel Marine Deck Fill with Key
LGRIG® Nylon Fuel Deck Fill with Keyless Cap
LGRIG® Nylon Fuel Deck Fill with Keyless Cap
China LG RIGGING's Updates
Exhibition in Norway 2024 LG RIGGING®
31
Jul
2025
Exhibition in Norway 2024 LG RIGGING® Learn More
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles
27
Jan
2025
In-depth Discussion on Quality Inspection and Maintenance of Lifting Gear Shackles Learn More
Introduction to Rigging Turnbuckles: Advantages and Applications
13
Jan
2025
Introduction to Rigging Turnbuckles: Advantages and Applications Learn More
Products
Trawling Gear Lifting & Rigging Stainless Steel Products Boat Fittings Pole Line Hardware Building Components
Resources
Video Blog FAQs About LG RIGGING® Document Download
About
Company News Industry News
Contact Us
Room 808, Dexin Building, No.788 Lanao Road, Jimo District, Qingdao, 266200, China.
sales@lg-lifting.com
+86 19524345486
Copyright © QINGDAO LG RIGGING CO.,LTD. All Rights Reserved.
Sitemap | Privacy Policy
sales@lg-lifting.com
+86 19524345486
