  • Description

Chain Swivel Flexible Stainless Steel WDF Type for fishing & trawling gear-China LG™ – AISI 304 or AISI 316 – China LG Supply

Description

Chain Swivel Flexible Stainless Steel WDF Type is more flexible than the standard swivels,also known as stainless steel flexible swivel.

This flexible swivel is hugely Popular Within the Boat, offshore, maritime, and commercial fishing and trawler. As it is Grade 304 or 316 Stainless Steel Giving Them The Best Rust Protection.

This stainless steel swivel FLEX has a safety factor ratio of 5:1,which means that it have the ability to hold five times the amount of their safe work load (SWL).

Remember, although the articulated swivel is rated to hold five times the rated SWL.Doing so is unsafe and is not recommended.

All the trawler swivel stainless steel passed the test and come with test certificates.



Technical & Application

MaterialStainless Steel AISI 304 or AISI 316 flexible swivel
Size13mm 16mm 19mm 22mm 25mm 28mm 32mm 38mm 45mm Swivel FLEX
Safety Factor5:1
ProcessingWelding / Machining / Highly Polishing
TipsFor various marine, Fishing, Trawling and industrial rigging applications
Important Notes*NOT FOR LIFTING*



Specification

Chain Swivel Flexible Stainless Steel WDF Type,aka trawl swivel,made of Marine Grade AISI 304/316 stainless steel,welded,used for trawling,China supplier

Part No.SizeWLL 5:1ABCDEWeight
mmtonmmmmmmmmmmkg
LG-SS-WDF-1313mm1.6302828341600.71
LG-SS-WDF-1616mm3.2413837482001.3
LG-SS-WDF-1919mm4.7444040542352
LG-SS-WDF-2222mm6.3444040552552.7
LG-SS-WDF-2525mm8.3555045703204.4
LG-SS-WDF-2828mm10.4555050803305.6
LG-SS-WDF-3232mm12555554933608.6
LG-SS-WDF-3838mm1862586011041013.5
LG-SS-WDF-4545mm2875707011551522.5

Real Goods Picture – Chain Swivel Flexible Stainless Steel WDF Type

Chain Swivel Flexible Stainless Steel WDF Type,aka trawl swivel,made of Marine Grade AISI 304/316 stainless steel,welded,used for trawling,China supplier

Chain Swivel Flexible Stainless Steel WDF Type,aka trawl swivel,made of Marine Grade AISI 304/316 stainless steel,welded,used for trawling,China supplier

Chain Swivel Flexible Stainless Steel WDF Type,aka trawl swivel,made of Marine Grade AISI 304/316 stainless steel,welded,used for trawling,China supplier

Chain Swivel Flexible Stainless Steel WDF Type,aka trawl swivel,made of Marine Grade AISI 304/316 stainless steel,welded,used for trawling,China supplier

Trawl Flexible Swivel Stainless Steel WDF Type,aka swivel stainless steel,made of Marine Grade AISI 304/316,been welded,used for trawling,China manufacturer







If you need help determining the right assembly or size for your application, e-mail our specialists at sales@lg-lifting.com for assistance. 🙂
