Wire Rope & Cable Grip 0.5Ton 1Ton 2Ton 3Ton

Wire Rope & Cable Grip 0.5Ton 1Ton 2Ton 3Ton, also known as Wire Rope Self Gripping Clamp.

Wire Rope Self Gripping Clamp, made from drop forged alloy steel for durability and toughness, which is specially heat treated. It is light and portable. yellow chromate finish protects grips from rust and corrosion.

Cable Wire Rope Grip Puller Pulling, after special heat treatment, the product has strong tension stress, high meshing degree and not easy slip or distort.

Wire Rope Grip Puller, parallel jaws provide firm gripsuitable for pulling electric cable, will not damage cable’s surface, Match with delicate smooth clamp mouth, minimal harm to wires.

Steel wire rope grip cable grip wire rope puller, guide prevents the grip from dropping off the cable and allows instant release.

Forged galvanized alloy steel wire rope cable grip, the rack has strong anti-tension with high occlusion strength. It is not easy to slide and deformation.

Wire Rope Grip/Clamp, the application of the tensioning device is applicable to the electric power, the operation of the industry, communications and agriculture, and the tightening of the rope line.


Notice

A cable puller with a maximum pulling force of 500KG. Capable of pulling cable of 1mm to 10mm in diameter.

A cable puller with a maximum pulling force of 1000KG. Capable of pulling cable of 2.5mm to 16mm in diameter, Apply to steel rope and steel stranded wire;

A cable puller with a maximum pulling force of 2000KG. Capable of pulling cable of 4mm to 22mm in diameter, Apply to steel rope and conductor wire;

A cable puller with a maximum pulling force of 3000KG. Capable of pulling cable of 16mm to 32mm in diameter, Apply to copper wire, aluminum wire, ACSR or aerial insulation line.

Warnings: Do not exceed rated capacity and always match proper size and type of grip to application. Before each use, make sure to clean jaw area and inspect grip for proper operation to avoid slippage.

Trawling Gear
Shackles
Boat Fittings

Information of Wire Rope & Cable Grip 0.5Ton 1Ton 2Ton 3Ton

Material

Sperior Alloy Steel

Finish

Color Zinc plated(yellow chromate)

WLL

0.5Ton, 1Ton, 2Ton, 3Ton

500kg, 1000kg, 2000kg, 3000kg

Note

Used for pulling up lines to tension only. Not to be used as anchors.


Specifications of Wire Rope & Cable Grip 0.5Ton 1Ton 2Ton 3Ton

Part No.

Capacity

Conductor diameter

Weight(kg)

LG-WRCC-0.5

0.5

1-10

0.25

LG-WRCC-1

1

2.5-16

0.6

LG-WRCC-2

2

4-22

1.3

LG-WRCC-3

3

16-32

1.36


Bulk photos of Wire Rope & Cable Grip 0.5Ton 1Ton 2Ton 3Ton

bulk photos of wire rope  cable grip 0
bulk photos of wire rope  cable grip 0
bulk photos of wire rope  cable grip 0
bulk photos of wire rope  cable grip 0
bulk photos of wire rope  cable grip 0
bulk photos of wire rope  cable grip 0
bulk photos of wire rope  cable grip 0
