Information of LGRIG® Grade 8 Alloy Bolt Type Chain Shackle

Brand	LGRIG®
Grade	Grade 8
Technical Notes	Meets or exceeds all requirements of ASME B30.26, Federal Specification RR-C-271, & ASTM A148M.
Safety Factor	5: 1
Shackle Type	Chain Shackle / D Shackle
Pin Type	Bolt Type Pin / Safety Pin
Material	Superior Alloy Steel
Processing	Drop Forged / Quenched and Tempered
Finish	Body: Hot Dipped Galvanized Pin: Powder Coating
Size	5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4”, 7/8”, 1”, 1-1/8”, 1-1/4”, 1-3/8”, 1-1/2”, 1-3/4”, 2”
WLL	1.2Ton, 1.6Ton, 2.5Ton, 3.3Ton, 5Ton, 7Ton, 9.5Ton, 12.5Ton, 15Ton, 18Ton, 21Ton, 30Ton, 40Ton, 55Ton
Tips	Special specification and marks can be made according to customers’ requirements

Specifications of LGRIG® Grade 8 Alloy Bolt Type Chain Shackle


Part No.	Size	Wight/LBS	WLL/T	B.L/T	A±1.5	D±1	N	L±3	L1±3	B
8LGCSBP5/16	5/16″	0.23	1.2	6	13.5	8	9.5	48.5	50.5	8.4
8LGCSBP3/8	3/8″	0.33	1.6	8	16.8	9.7	11	58.4	62	10.8
8LGCSBP7/16	7/16″	0.49	2.5	12.5	19	11.2	13	67.6	70	12.8
8LGCSBP1/2	1/2″	0.75	3.3	16.5	20.6	12.7	16	77	79.9	14.8
8LGCSBP5/8	5/8″	1.47	5	25	27	17.5	19	97.3	1101.5	18
8LGCSBP3/4	3/4″	2.52	7	35	32	20.6	22	116.6	117.5	19.4
8LGCSBP7/8	7/8″	3.85	9.5	47.5	36.6	24.6	25	135.4	136	21.5
8LGCSBP1/1	1″	5.55	12.5	62.5	43	27	28	152.4	153.5	23.8
8LGCSBP1-1/8	1-1/8″	7.6	15	75	46	31.8	32	172.4	171.5	25.6
8LGCSBP1-1/4	1-1/4″	10.81	18	90	51.6	35	35	190.5	192	31
8LGCSBP1-3/8	1-3/8″	13.75	21	105	57	35	38	206.8	202	33.4
8LGCSBP1-1/2	1-1/2″	18.5	30	150	60.5	41	42	230.1	222	34
8LGCSBP1-3/4	1-3/4″	31.4	40	200	73.2	53.8	51	279	278	38
8LGCSBP2/1	2″	46.75	55	275	82.5	61	57	324.6	307	45
