Drop Forged Jaw & Eye Turnbuckle Stainless Steel US Type

Drop Forged Jaw & Eye Turnbuckle Stainless Steel US Type is made from marine grade stainless steel AISI304 or AISI316, which has the highest level of rust resistance.

Stainless steel turnbuckle forged with jaw and eye ends, and you also could match with the other end, such as hook ends.

Forging stainless steel jaw and eye turnbuckle conformed to US federal specification, been forged to meet your high requirements.

The forged turnbuckle eye & eye is a valuable commodity for rigging for their fast connect/disconnect properties.

Customized is available, pls send us your drawing.

Trawling Gear
Boat Fittings

Information of Drop Forged Jaw & Eye Turnbuckle Stainless Steel US Type

Technical Notes

Forged Turnbuckle conform to US Federal Specification

Material

Stainless steel 304 and 316 turnbuckle

Size

1/4×4, 5/16×4 1/2, 3/8×6, 1/2×6, 1/2×9, 1/2×12, 5/8×6, 5/8×9, 5/8×12

3/4×6,3/4×9, 3/4×12, 3/4×18, 7/8×12, 7/8×18 , 1×6, 1×12 , 1×18, 1×24

1 1/4×12,1 1/4×18, 1 1/4×24, 1 1/2×12, 1 1/2×18, 1 1/2×24, 1 3/4×18, 1 3/4×24

2×24, 2 1/2×24, 2 3/4×24

Processing

Drop Forged

Tips

Corrosion Resistant


Specifications of Drop Forged Jaw & Eye Turnbuckle Stainless Steel US Type

Specifications of Drop Forged Jaw & Eye Turnbuckle Stainless Steel US Type


Part  No.

Thread Dia
&
Take Up

Working limited

Weight

Dimensions(in)

B

E

G

J

K

R

S

(lbs)

(lbs)

Closed

Open

Closed

LG-SS-F-TB-JE-US-1/4×4

1/4×4

500

0.33

0.45

1.66

0.64

11.57

7.57

0.81

0.34

LG-SS-F-TB-JE-US-5/16×4-1/2

5/16×4-1/2

800

0.52

0.5

2.02

0.87

13.5

9

0.95

0.44

LG-SS-F-TB-JE-US-3/8×6

3/8×6

1200

0.8

0.53

2.11

0.85

16.91

10.91

1.13

0.53

LG-SS-F-TB-JE-US-1/2×6

1/2×6

2200

1.77

0.64

3.22

1.07

19.3

13.3

1.41

0.71

LG-SS-F-TB-JE-US-1/2×9

1/2×9

2200

2.25

0.64

3.2

1.07

25.59

16.59

1.41

0.71

LG-SS-F-TB-JE-US-1/2×12

1/2×12

2200

2.67

0.64

3.2

1.07

31.59

19.59

1.41

0.71

LG-SS-F-TB-JE-US-5/8×6

5/8×6

3500

2.98

0.79

3.9

1.32

20.73

14.73

1.8

0.88

LG-SS-F-F-TB-JE-US-5/8×9

5/8×9

3500

3.72

0.79

3.89

1.32

27.07

18.07

1.8

0.88

LG-SS-F-TB-JE-US-5/8×12

5/8×12

3500

4.35

0.79

3.89

1.32

33.07

21.07

1.8

0.88

LG-SS-F-TB-JE-US-3/4×6

3/4×6

5200

4.51

0.97

4.71

1.52

22.17

16.17

2.09

1

LG-SS-F-TB-JE-US-3/4×9

3/4×9

5200

5.56

0.97

4.68

1.52

28.57

19.57

2.09

1

LG-SS-F-TB-JE-US-3/4×12

3/4×12

5200

6.42

0.97

4.68

1.52

34.57

22.57

2.09

1

LG-SS-F-TB-JE-US-3/4×18

3/4×18

5200

8.14

0.97

4.71

1.52

46.57

28.57

2.09

1

LG-SS-F-TB-JE-US-7/8×12

7/8×12

7200

9.1

1.16

5.5

1.77

35.68

23.68

2.38

1.25

LG-SS-F-TB-JE-US-7/8×18

7/8×18

7200

11.6

1.16

5.5

1.77

48.15

30.15

2.38

1.25

LG-SS-F-TB-JE-US-1×6

1×6

10000

10

1.34

6.09

2.05

25.03

19.03

3

1.43

LG-SS-F-TB-JE-US-1×12

1×12

10000

13.4

1.34

6.09

2.05

37.03

25.03

3

1.43

LG-SS-F-TB-JE-US-1×18

1×18

10000

16.7

1.34

6.09

2.05

49.03

31.03

3

1.43

LG-SS-F-TB-JE-US-1×24

1×24

10000

20.6

1.34

6.06

2.05

61.63

37.63

3

1.43

LG-SS-F-TB-JE-US-1-1/4×12

1-1/4×12

15200

20.9

1.84

8.09

2.82

40.76

28.76

3.59

1.82

LG-SS-F-TB-JE-US-1-1/4×18

1-1/4×18

15200

24.8

1.84

8.09

2.82

52.76

34.76

3.59

1.82

LG-SS-F-TB-JE-US-1-1/4×24

1-1/4×24

15200

28.8

1.84

8.09

2.82

65.32

41.32

3.59

1.82

LG-SS-F-TB-JE-US-1-1/2×12

1-1/2×12

21400

30.6

2.06

8.93

2.81

42.5

30.5

4.09

2.12

LG-SS-F-TB-JE-US-1-1/2×18

1-1/2×18

21400

36

2.06

8.93

2.81

54.5

36.5

4.09

2.12

LG-SS-F-TB-JE-US-1-1/2×24

1-1/2×24

21400

41.5

2.06

8.93

2.81

67.12

43.12

4.09

2.12

LG-SS-F-TB-JE-US-1-3/4×18

1-3/4×18

28000

52.1

2.6

9.36

3.35

55.37

37.37

4.65

2.38

LG-SS-F-TB-JE-US-1-3/4×24

1-3/4×24

28000

59.7

2.6

9.36

3.35

67.37

43.37

4.65

2.38

LG-SS-F-TB-JE-US-2×24

2×24

37000

89.9

2.62

11.8

3.74

72.66

48.66

5.81

2.69

LG-SS-F-TB-JE-US-2-1/2×24

2-1/2×24

60000

158

3.06

13.26

4.44

76.08

52.08

6.49

3.12

LG-SS-F-TB-JE-US-2-3/4×24

2-3/4×24

75000

187

3.69

14.92

4.19

78.05

54.05

7

3.25


We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
