 D Type Joining Shackles Grade U2 & U3 LG RIGGING®

 Swivel Forerunner Grade U2 & 3 Anchor Chain Accessories LG RIGGING®

 Stainless Steel Delta Anchor DT Type LG RIGGING®

 Galvanised Plough/CQR Anchor LG RIGGING®

 Galvanised Folding Grapnel Anchor LG RIGGING®

 Galvanised Bruce/Claw Boat Anchor LG RIGGING®

 Galvanised Crown Stock Anchor Danforth Anchors LG RIGGING®

 Stainless Steel Folding Grapnel Anchor LG RIGGING®

 Stainless Steel Danforth Anchors Crown Stock Anchor LG RIGGING®

 Stainless Steel Four Prong Grapnel Anchor LG RIGGING®

 Stainless Steel Claw/Bruce Boat Anchor LG RIGGING®

Wire Rope Clips 

Ferrules & Terminals 

Rigging Screws 

Fishing Net Float 

Fenders & Buoys 

Lashing/Slings/Load Binders 

Trawl Blocks & Pulley 

Toggles & Spacers 

Safety Appliance 

Footrope Gear 

Trawl Door 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Informations of Kenter Shackle Grade U2 & U3 LG RIGGING®

Brand	LG RIGGING®
Standard	ISO 1704
Material	Steel CM490/CM690
Surface Finish	Hot-dip galvanized \| Electro-galvanized \| Black Painting
Grade	U2 & U3
Function	Positive interlock for anchor chain connections
Marine applications	Critical mooring/anchor chain joining systems
Sizing	11-162mm nominal diameter (full dimensional compliance with DIN 6919)
QA Certificates	DNV/GL/ABS/BV/RINA/NK/KR/LRS/RS/IRS
Country of Origin	China

Specifications of Kenter Shackle Grade U2 & U3 LG RIGGING®


Part No.	Nominal DIA. mm	Weight kg	Part No.	Nominal DIA. mm	Weight kg	Part No.	Nominal DIA. mm	Weight kg
LGAKS011	11	0.47	LGAKS050	50	19.00	LGAKS100	100	146.00
LGAKS012.5	12.5	0.54	LGAKS052	52	20.30	LGAKS102	102	158.00
LGAKS014	14	0.60	LGAKS054	54	23.70	LGAKS105	105	160.00
LGAKS016	16	0.65	LGAKS056	56	26.70	LGAKS107	107	180.00
LGAKS017.5	17.5	0.88	LGAKS058	58	27.20	LGAKS111	111	198.00
LGAKS019	19	1.13	LGAKS060	60	27.70	LGAKS114	114	204.00
LGAKS020.5	20.5	1.36	LGAKS062	62	35.00	LGAKS117	117	225.00
LGAKS022	22	1.64	LGAKS064	64	38.40	LGAKS120	120	250.00
LGAKS024	24	2.13	LGAKS066	66	42.30	LGAKS122	122	263.00
LGAKS026	26	2.58	LGAKS068	68	46.00	LGAKS124	124	290.00
LGAKS028	28	3.30	LGAKS070	70	48.70	LGAKS127	127	312.00
LGAKS030	30	4.15	LGAKS073	73	53.00	LGAKS130	130	333.00
LGAKS032	32	5.06	LGAKS076	76	60.70	LGAKS132	132	350.00
LGAKS034	34	6.01	LGAKS078	78	65.50	LGAKS137	137	392.00
LGAKS036	36	6.89	LGAKS081	81	75.00	LGAKS142	142	436.00
LGAKS038	38	8.40	LGAKS084	84	90.00	LGAKS147	147	485.00
LGAKS040	40	9.63	LGAKS087	87	96.00	LGAKS152	152	537.00
LGAKS042	42	11.00	LGAKS090	90	108.00	LGAKS157	157	591.00
LGAKS044	44	12.45	LGAKS092	92	114.00	LGAKS162	162	651.00
LGAKS044	46	14.10	LGAKS095	95	128.00
LGAKS048	48	16.70	LGAKS097	97	133.00
