Stainless Steel Wire Rope Clips DIN741

Stainless Steel Wire Rope Clips DIN741, also known as Wire Rope Grips or Wire Rope Clamps.

Wire rope grip conform to DIN741, made from stainless steel 304 or 316, has great rust resistance, very durable.

Wire rope clip DIN741, fittings used to make an eye or join two cable or wire rope ends together.

The two layers of wire rope, placed in the U-bolt.

The saddle,then fitted over the ropes on to the bolt (the saddle includes two holes to fit to the u-bolt).

The nuts secure the arrangement in place.

Our stainless steel wire rope clips DIN741, perfect for use with wire rope when being used aboard boats, public areas, yacht rigging and many more.

Trawling Gear
Boat Fittings

Information of Stainless Steel Wire Rope Clips DIN741

Technical Notes

Wire rope clip conform to DIN 741

Material

Stainless steel 304 or 316

Processing

Cast

Finish

Highly Polished

Size

3mm, 5mm, 6mm, 8mm, 10mm, 11mm, 13mm, 14mm, 16mm, 19mm, 22mm, 26mm, 30mm, 32mm, 34mm, 40mm


Specifications of Stainless Steel Wire Rope Clips DIN741

Specifications of Stainless Steel Wire Rope Clips DIN741


Part No.

Size

A

B

C

D

E

F

G

mm

LG-SS-741-03

3

9

10

12

4

10

21

16

LG-SS-741-05

5

11

11

13

5

10

23

19

LG-SS-741-06

6

13

12

15

5

11

26

23

LG-SS-741-08

8

16

14

19

6

15

30

28

LG-SS-741-10

10

19

18

22

8

17

34

34

LG-SS-741-11

11

20

19

22

8

18

36

36

LG-SS-741-13

13

24

23

30

10

21

42

45

LG-SS-741-14

14

25

23

30

1

22

44

47

LG-SS-741-16

16

29

26

33

12

26

50

51

LG-SS-741-19

19

32

29

38

12

30

54

63

LG-SS-741-22

22

37

33

44

14

34

61

71

LG-SS-741-26

26

41

35

45

14

37

65

81

LG-SS-741-30

30

50

40

50

16

50

80

94

LG-SS-741-32

32

50

40

50

16

50

80

102

LG-SS-741-34

34

54

45

55

16

55

88

104

LG-SS-741-40

40

60

48

60

16

60

95

124


Please note we supply a huge variety of stainless steel parts.
