Tube Thimble Stainless Steel with Gusset

Our Tube Thimble Stainless Steel with Gusset comes in stainless steel for added resistance to high moisture or corrosive environments.

tubular thimble is easy to install, it well keep the rope line into the tube groove, avoid the line fall off from thimble. make safer on working. This tube thimble will protect your line and keep it from twisting and fraying at the ends. Our range of tube thimble is available in standard as well as customized sizes.

Stainless steel tubular thimble is one kind of wire rope thimble , and it is deal for marine and industrial rigging and wire rope applications.

Get A Quote
Products
Trawling Gear
Fishing Net Float & Buoy
Trawling Swivel
Trawling Shackle
Grade80 / Grade100
Rope Thimbles
Rope Splicing Spike
Hooks / Links / Rope Fittings
Trawling Chain
Lifting Sling
Trawl Block
Wire / Chain Toggles
Anchors & Fittings
Dock Products
Safety Appliance
Lifting & Rigging
G100 Products
G80 Products
Turnbuckles
Wire Ropes Clips & Grips
Eye Bolts & Nuts
Forged Hooks
Wire Rope
Chain Binders
Forged Rings & Connector
Lever Hoist
Lifting Sling of Lifting & Rigging
Shackles
Quick Links
Snap Hooks
Wire Rope Thimbles
Pulley & Blocks
Lifting & Rigging Pins
Forestry Logging Supplies
Swivels
Chains & Accessories
Ratchet Straps
Wire Rope Sleeves/Ferrules
Eye Plate
Stainless Steel Products
Stainless U Bolts
Stainless Thimbles
Tubular Thimble Stainless Steel-LG RIGGING®
Tube Thimble Cast Stainless Steel without Gusset
Tubular Thimble Stainless Steel Light Duty
Tubular Thimble Stainless Steel Heavy Duty
Tubular Thimble Cast Stainless Steel with Gusset
Tube Thimble Stainless Steel with Gusset
Thimble Wire Rope G-414 Heavy Duty Stainless Steel
Thimble Wire Rope G-411 Light Duty Stainless Steel
Stainless Steel Wire Rope Thimble European Type
Stainless Steel Wire Rope Thimble Italian Type
Stainless Terminals
Stainless Swivels
Stainless Hinge
Stainless Shackles
Stainless Rings
Stainless Quick Link
Stainless Pulleys
Stainless Hooks & Clips
Stainless Wire Clips
Shade Sail Hardware
Drop Forged Stainless Products
Stainless Turnbuckle
Stainless Chains
Stainless Eye Bolts & Nuts
Eye Plate, Eye Straps, Angles
Boat Fittings
Stainless Marine Hinges
Bimini Top Fittings
Cleats & Fairleads
Angle Bracket
Rail Fittings
Thru-Hull & Deck Fittings
Stainless Latches
Pole Line Hardware
A-Cable Suspension Bolt-China LG Manufacture
Adjusting Plate for Power Line-China LG Manufacture
Angle Eye Bolt Pole Line Hardware-China LG Supply
Cable Span Clamps Pole Line Hardware-China LG Manufacture
Carriage Bolts For Overhead Line Construction-China LG Supply
Crossover Clamp-China LG Manufacture
Electric Power Bow/Dee Shackle for Power Line-China LG Supply
Electric Power Eye Shaft Screw Anchor-China LG Supply
Electric Power Socket Clevis WSY-China LG Manufacture
Electric Power Socket Clevis-Double Type-Line Hardware-LG RIGGING®
Electric Power Socket Clevis-Single Type-Line Hardware-China LG Supply
Electric Power Thimble Eye Nut-China LG Manufacture
Electric Power U Ball Clevis-China LG Manufacture
Electrical Wire Cable Thimble Clevis-China LG Supply
Forged Eye Bolt For Anchor Assemble-China LG Supply
Forged Oval Eye Nut for Pole Line Fitting-China LG Supply
Forged Steel Ball Eye for Electric Fitting-China LG Supply
Forged Steel Galvanized Joint Hung Plate-LG RIGGING®
Galvanized Insulator Clevis D Iron Bracket-China LG Supply
Galvanized Steel Ball Eye Pole Line Hardware-China LG Supply
Galvanized Thimble Eye Anchor Rod-China LG Supply
Guy Clamp for Pole Line Hardware-China LG Manufacture
High Strength Carbon Steel Galvanized U-Bolts-LG RIGGING®
High Strength Helical Spring Lock Washer-LG RIGGING®
Hot Dip Galvanized Square Curved Cast Washer-LG RIGGING®
Hot Dip Galvanized Steel Clevis Power Fitting-LG RIGGING®
Hot Dip Galvanized Steel Yoke Plate-China LG Supply
Hot-Dip Galvanized Guy Clips-China LG Manufacture
Hot-Dip Galvanized Steel Yoke Plate for Power Line-LG RIGGING®
MF Curved Locknut Square Type-China LG Manufacture
Pole Line Forged Single Thimble Eye Nut-China LG Supply
Pole Line Hardware Forged Ball Eye-China LG Manufacture
Pole Line Hardware Forged Y Type Ball Clevis and Eye-LG RIGGING®
Pole Line Hardware Oval PH Type Chain Link-China LG Supply
Pole Line Hardware Y Type Ball Clevis-China LG Manufacture
Pole Line Hardware ZH Type Chain Link-China LG Supply
Spring Clip Washer Pole Line Fastener-China LG Supply
Square Curved Washer Pole Line Hardware-LG RIGGING®
Square Nut Hot Dip Galvanized-China LG Manufacture
Stainless Steel Round Flat Washer-China LG Manufacture
Steel PT Type Adjustment Plate-China LG Manufacture
Steel Round Pole Band Pole Clamp for Electric Power-LG RIGGING®
Straight Thimble Eye Bolt Pole Line Hardware-LG RIGGING®
Suspension Clamp for Overhead Line-China LG Supply
Tension Clamp for Aluminium Conductor-LG RIGGING®
Tower Pole Step Bolt with Nut-China LG Manufacture
Transformer Bracket Steel Single-Band Component-LG RIGGING®
Triple Eye Anchor Pole Line Hardware-China LG Supply
U Shape Anchor Shackle Pole Line Hardware-LG RIGGING®
U Type Yoke Plate for Line Fitting-China LG Manufacture

Information of Tube Thimble Stainless Steel with Gusset

Material

Stainless steel AISI304 / 316

Processing

Machining / Stamping / Welding

Finish

Highly polishing / Electrophoretic Coating

Size-Wire

15-12mm, 19-16mm24-21mm, 27-24mm, 31-28mm, 39-35mm, 48-44mm, 60-54mm

Tips

Supplied in open finish or with welded gusset plate


Specifications of Tube Thimble Stainless Steel with Gusset

Specifications of Tube Thimble Stainless Steel with Gusset


Part No.

A

B

C

D

E

F

Weight

For wire max.

mm

kg

mm

LG-G808K

8

60

17

3.0

7

30

0.09

6

LG-G810K

10

70

20

3.0

9

33

0.13

8

LG-G812K

12

84

20

4.0

7

34

0.35

10

LG-G815K

15

91

27

5.0

9

32

0.41

12

LG-G819K

19

113

31

5.0

11

46

0.62

16

LG-G824K

24

136

46

5.0

15

57

1.11

21

LG-G827K

27

142

45

5.0

15

62

1.36

24

LG-G831K

31

163

48

7.0

19

66

1.92

28

LG-G839K

39

179

60

5.5

20

83

1.79

35

LG-G848K

48

220

74

5.5

32

82

2.90

44

LG-G860K

60

260

100

8.5

38

90

5.90

54


We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
Contact LG RIGGING NOW
Contact LG RIGGING
Tel:
+86-0532-66851176
E-mail:
Add:
A408, Sungwon Foreign Trade Center, No.187 Heilongjiang Middle Road, Chengyang District, Qingdao, China.
Request a Free Quote
Upload
or drag files here.

Related Stainless Thimbles

Tubular Thimble Stainless Steel Light Duty
Tubular Thimble Stainless Steel Light Duty
Thimble Wire Rope G-411 Light Duty Stainless Steel
Thimble Wire Rope G-411 Light Duty Stainless Steel
Thimble Wire Rope G-414 Heavy Duty Stainless Steel
Thimble Wire Rope G-414 Heavy Duty Stainless Steel
Stainless Steel Wire Rope Thimble European Type
Stainless Steel Wire Rope Thimble European Type
Tube Thimble Cast Stainless Steel without Gusset
Tube Thimble Cast Stainless Steel without Gusset
Tubular Thimble Stainless Steel Heavy Duty
Tubular Thimble Stainless Steel Heavy Duty
Stainless Steel Wire Rope Thimble Italian Type
Stainless Steel Wire Rope Thimble Italian Type
Tubular Thimble Stainless Steel-LG RIGGING®
Tubular Thimble Stainless Steel-LG RIGGING®
China LG RIGGING's Updates
Application Characteristics and Analysis of Lifting Chain Rigging
22
Nov
2022
Application Characteristics and Analysis of Lifting Chain Rigging Learn More
About The Connection of Fixed Stainless Steel Wire Rope Thimble and Rope Clip
08
Nov
2022
About The Connection of Fixed Stainless Steel Wire Rope Thimble and Rope Clip Learn More
Stainless Steel Wire Rope Rigging
18
Oct
2022
Stainless Steel Wire Rope Rigging Learn More
Products
Trawling Gear Lifting & Rigging Stainless Steel Products Boat Fittings Pole Line Hardware
Resources
FAQs About LG RIGGING® Document Download Blog
About
Company News Industry News
Contact Us
A408, Sungwon Foreign Trade Center, No.187 Heilongjiang Middle Road, Chengyang District, Qingdao, China.
sales@lg-lifting.com
+86-0532-66851176
Copyright © QINGDAO LG RIGGING CO.,LTD. All Rights Reserved.
Sitemap | Privacy Policy
sales@lg-lifting.com
+86-0532-66851176
