Lynch Pin Zinc Plated – LG RIGGING®

Lynch Pin Zinc Plated, also known as linch pins.

Lynch pin, designed for quick disconnect applications, these pins are made from 1010 carbon steel with a Rockwell hardness of 50-60.

Our lynch pins, forged for maximum strength, they are available with an 8″ plated chain for added security, including a cotter pin for protection against loss or misplacement.

These linch pins, are pins were designed to stop Linkage wheels and other parts from sliding off of the axle.

Trailer lynch pin, are most commonly used to secure implements onto tractor lift arms in conjunction with linkage pins.

Tractor linch pins, are tough and durable and designed to withstand the wear and tear of everyday use. The Pins come in various sizes.

Trawling Gear
Shackles
Boat Fittings

Information of Lynch Pin Zinc Plated – China LG™

Material

Superior Carbon Steel

Finish

Electric Galvanized(Yellow Zinc Plated)

Size

3/16″, 1/4″, 5/16″, 7/16″

Tips

Special specification and marks can be made according to customers’ requirements


Specifications of Lynch Pin Zinc Plated – China LG™

Specifications of Lynch Pin Zinc Plated – China LG™


Part No.

(A)


Outside

Diameter

(E)


Effective

Length
+.079/-.039

(B)


Shank

Length
+.040/-.040″

(H)


Inside

Diameter

LGLPRZP-187-0875

.188″ (3/16)

.875″ (7/8)

1.125″ (1-1/8)

1.000″ (1)

LGLPRZP-187-1000

.188″ (3/16)

1.000″ (1)

1.250″ (1-1/4)

1.125″ (1-1/8)

LGLPRZP-187-1250

.188″ (3/16)

1.250″ (1-1/4)

1.563″ (1-9/16)

1.406″ (1-13/32)

LGLPRZP-187-1312

.188″ (3/16)

1.313″ (1-5/16)

1.563″ (1-9/16)

1.438″ (1-7/16)

LGLPRZP-250-1250

.250″ (1/4)

1.250″ (1-1/4)

1.563″ (1-9/16)

1.406″ (1-13/32)

LGLPRZP-250-1250A

.250″ (1/4)

1.250″ (1-1/4)

1.750″ (1-3/4)

1.406″ (1-13/32)

LGLPRZP-250-1312

.250″ (1/4)

1.313″ (1-5/16)

1.750″ (1-3/4)

1.438″ (1-7/16)

LGLPRZP-250-1375

.250″ (1/4)

1.375″ (1-3/8)

1.750″ (1-3/4)

1.500″ (1-1/2)

LGLPRZP-250-1500

.250″ (1/4)

1.500″ (1-1/2)

1.750″ (1-3/4)

1.563″ (1-9/16)

LGLPRZP-250-1625

.250“ (1/4)

1.625″ (1-5/8)

1.750″ (1-3/4)

1.688″ (1-11/16)

LGLPRZP-250-1750

.250“ (1/4)

1.750″ (1-3/4)

2.000″ (2)

1.875″ (1-7/8)

LGLPRZP-312-1250

.313″ (5/16)

1.250″ (1-1/4)

1.563″ (1-9/16)

1.406″ (1-13/32)

LGLPRZP-312-1250A

.313″ (5/16)

1.250″ (1-1/4)

1.750″ (1-3/4)

1.406″ (1-13/32)

LGLPRZP-312-1375

.313″ (5/16)

1.375″ (1-3/8)

1.750″ (1-3/4)

1.500″ (1-1/2)

LGLPRZP-312-1500

.313″ (5/16)

1.500″ (1-1/2)

1.750″ (1-3/4)

1.563″ (1-9/16)

LGLPRZP-312-1625

.313″ (5/16)

1.625″ (1-5/8)

2.344″ (2-11/32)

1.875″ (1-7/8)

LGLPRZP-312-1625A

.313″ (5/16)

1.625″ (1-5/8)

2.375″ (2-3/8)

1.875″ (1-7/8)

LGLPRZP-312-1750

.313″ (5/16)

1.750″ (1-3/4)

2.000″ (2)

1.875″ (1-7/8)

LGLPRZP-312-2062

.313″ (5/16)

2.063″ (2-1/16)

2.344″ (2-11/32)

2.188″ (2-3/16)

LGLPRZP-437-1250

.438″ (7/16)

1.250″ (1-1/4)

1.750″ (1-3/4)

1.406″ (1-13/32)

LGLPRZP-437-1343

.438″ (7/16)

1.344″ (1-11/32)

1.563″ (1-9/16)

1.531″ (1-17/32)

LGLPRZP-437-1343A

.438″ (7/16)

1.344″ (1-11/32)

1.969″ (1-31/32)

1.531″ (1-17/32)

LGLPRZP-437-1375

.438″ (7/16)

1.375″ (1-3/8)

1.750″ (1-3/4)

1.500″ (1-1/2)

LGLPRZP-437-1437

.438″ (7/16)

1.438″ (1-7/16)

2.000″ (2)

1.531″ (1-17/32)

LGLPRZP-437-1500

.438″ (7/16)

1.500″ (1-1/2)

2.000″ (2)

1.563″ (1-9/16)

LGLPRZP-437-1500A

.438″ (7/16)

1.500″ (1-1/2)

1.750″ (1-3/4)

1.563″ (1-9/16)

LGLPRZP-437-1500B

.438″ (7/16)

1.500″ (1-1/2)

1.969″ (1-31/32)

1.563″ (1-9/16)

LGLPRZP-437-1625

.438″ (7/16)

1.625″ (1-5/8)

1.938″ (1-15/16)

1.875″ (1-7/8)

LGLPRZP-437-1750

.438″ (7/16)

1.750″ (1-3/4)

2.250″ (2-1/4)

2.000″ (2)

LGLPRZP-437-2250

.438″ (7/16)

2.250″ (2-1/4)

2.500″ (2-1/2)

2.625″ (2-5/8)


We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
