 DIN 764 Medium Link Chain

 DIN 766 Short Link Chain

 Calibrated Anchor Chain DIN 766

 Calibrated Anchor Chain DIN 766 Stainless Steel

 DIN 5685 A/C Short/Long Link Chain

 Austrilian Standard Short Link Chain

 Regular Link Proof Coil Chain Australian Standard

 Long Link Proof Coil Chain Australian Standard

 Long Link Trailer Safety Chains NZS5467 G70

 Grade L Lifting Chain G30 Galvanised

 Australian Standard Grade 70 Chain

 Studless Link Anchor Chain Common Link

 Grade U1 U2 U3 Stud Link Anchor Chain Common Link

 Grade 70 Chain Anchor with Delta Ring and Grab Hook

 Grab Hook w/ 18'' Chain Anchor Pear Ring

 Trailer Safety Chain with 2 ''S'' Hooks Grade 30

 G43/ G70 Chain With Clevis Hooks/Eye Hooks

 Straight Link Coil Chain, Zinc Plated

 Twist Link Coil Chain, Zinc Plated

 Double Loop Weldless Chain

 Sash Chains, Weldless Chain

 Cold Shut Chain Links

 Zinc Plated Chain Lap / Repair Link, Mending Link

 Clevis Lug Links Grade 70 Australia Standard

 Split Connecting Links, Chain Connecting Links, G-335 Missing Link

 Grade 43 High Test Chain, Towing Chain

 Fishing Link Chain G80 Alloy Steel of Chains and Accessories

 Grade 80 Alloy Lifting Chains EN818-2 of Chains and Accessories

 Grade 100 Alloy Lifting Chain EN818-2 of Chains and Accessories

 G80 Alloy Lifting Chain EN818-7 of Chains and Accessories

 Twin Clevis Link of Chains and Accessories

 Double Clevis Link Forged Steel of Chains and Accessories

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Information of Split Connecting Links, Chain Connecting Links, G-335 Missing Link

Forged steel, Quenched and Tempered.
Hot-dip galvanized.
Have rivets only – no interlocking lugs.
Has reinforced rivet holes. All Sizes have countersunk rivet holes.
Ultimate Load is 4 times the Working Load Limit.
Meets Design Requirements of Federal Specification RR-C-271D, Type II.

Available Size for Split Connecting Links, Chain Connecting Links, G-335 Missing Link:

5mm (3/16”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link;

7mm (1/4”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link;

8mm(5/16”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link;

10mm(3/8”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link;

11mm(7/16”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link;

13mm(1/2”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link;

16mm(5/8”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link;

19mm(3/4”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link;

22mm(7/8”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link;

26mm(1”) Split Connecting Links, Chain Connecting Links, G-335 Missing Link.

Specifications of Split Connecting Links, Chain Connecting Links, G-335 Missing Link

Code No.		Chain Size		W.L.L (lbs.)	Weight per 100	Dimensions (in.)
Carbon Steel	Stainless Steel	inch	mm	W.L.L (lbs.)	Weight per 100	A	B	C	D	E	F	G
LGG33505	LGS33505	3/16”	5	800	2.5	0.25	0.69	0.34	0.34	1.19	0.78	0.28
LGG33507	LGS33507	1/4”	7	1325	6.25	0.28	0.88	0.44	0.44	1.5	1	0.31
LGG33508	LGS33508	5/16”	8	1950	12.5	0.34	0.94	0.47	0.47	1.69	1.16	0.38
LGG33510	LGS33510	3/8”	10	2750	20	0.41	1.13	0.56	0.56	2.06	1.38	0.47
LGG33511	LGS33511	7/16”	11	3625	27.5	0.47	1.28	0.59	0.59	2.34	1.53	0.53
LGG33513	LGS33513	1/2”	13	4750	37.5	0.53	1.47	0.66	0.66	2.66	1.72	0.59
LGG33516	LGS33516	5/8”	16	7250	72.5	0.66	1.81	0.78	0.81	3.31	2.09	0.75
LGG33519	LGS33519	3/4”	19	10250	122.5	0.78	2.13	0.94	1.06	3.88	2.5	0.88
LGG33522	LGS33522	7/8”	22	12000	175.5	0.91	2.5	1.13	1.13	4.5	2.94	1
LGG33526	LGS33526	1”	26	15500	250	1.03	2.75	1.25	1.25	5	3.31	1.13
