Cable Ferrule Stainless Steel DIN 3093(EN 13411-3)

Cable Ferrule Stainless Steel DIN 3093 also called wire rope sleeve, conform to DIN 3093, also known as EN 13411-3.

And wire rope sleeve is made of stainless steel, been squeezed and machined.

Stainless steel cable ferrule is great for safety in fabrication and application.

Wire rope ferrule stainless steel can be easily attached to wire rope directly by crimping tools.

Our range of wire rope sleeves is available in standard as well as customized sizes.

Trawling Gear
Shackles
Boat Fittings

Information of Cable Ferrule Stainless Steel DIN 3093(EN 13411-3)

Material

Stainless Steel AISI304/AISI316

Processing

Machining + Extruded

Size

1mm, 1.5mm, 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 6mm, 6.5mm, 7mm , 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 16mm, 18mm, 20mm, 22mm, 24mm, 26mm, 28mm, 30mm, 32mm, 34mm, 36mm, 38mm, 40mm, 42mm, 44mm, 46mm, 48mm, 50mm, 52mm, 54mm, 56mm, 58mm, 60mm


Specifications of Cable Ferrule Stainless Steel DIN 3093(EN 13411-3)

Part No.

Size

A(mm)

B(mm)

S(mm)

L(mm)

Weight


kgs/1000pcs

L'(mm)

LG-SS3093-01

1

1.2

2.4

0.65

5

0.098

LG-SS3093-1.5

1.5

1.7

3.4

0.75

6

0.176

LG-SS3093-02

2

2.2

4.4

0.85

7

0.285

LG-SS3093-2.5

2.5

2.7

5.4

1.05

9

0.439

LG-SS3093-03

3

3.3

6.6

1.25

11

0.907

LG-SS3093-3.5

3.5

3.8

7.6

1.5

13

1.18

LG-SS3093-04

4

4.4

8.8

1.7

14

1.63

LG-SS3093-4.5

4.5

4.9

9.8

1.9

16

2.39

LG-SS3093-05

5

5.5

11

2.1

18

3.62

LG-SS3093-06

6

6.6

13.2

2.5

21

5.87

25

LG-SS3093-6.5

6.5

7.2

14.4

2.7

23

7.18

LG-SS3093-07

7

7.8

15.6

2.9

25

9.83

30

LG-SS3093-08

8

8.8

17.6

3.3

28

12.96

34

LG-SS3093-09

9

9.9

19.8

3.7

32

18.94

38

LG-SS3093-10

10

10.9

21.8

4.1

35

24.09

42

LG-SS3093-11

11

12.1

24.2

4.5

39

35.35

47

LG-SS3093-12

12

13.2

26.4

4.9

42

44.18

50

LG-SS3093-13

13

14.2

28.4

5.4

46

59.86

55

LG-SS3093-14

14

15.3

30.6

5.8

49

73.5

59

LG-SS3093-16

16

17.5

35

6.7

56

111

67

LG-SS3093-18

18

19.6

39.2

7.6

63

156

76

LG-SS3093-20

20

21.7

43.4

8.4

70

217

84

LG-SS3093-22

22

24.3

48.6

9.2

77

292

92

LG-SS3093-24

24

26.4

52.8

10

84

376

101

LG-SS3093-26

26

28.5

57

10.9

91

481

109

LG-SS3093-28

28

31

62

11.7

98

603

118

LG-SS3093-30

30

33.1

66.2

12.5

105

739

126

LG-SS3093-32

32

35.2

70.4

13.4

112

897

134

LG-SS3093-34

34

37.8

75.6

14.2

119

1077

143

LG-SS3093-36

36

39.8

79.6

15

126

1275

152

LG-SS3093-38

38

41.9

83.8

15.8

133

1503

160

LG-SS3093-40

40

44

88

16.6

140

1734

168

LG-SS3093-42

42

46.2

92.4

17.5

147

2024

LG-SS3093-44

44

48.4

96.8

18.3

154

2314

184

LG-SS3093-46

46

50.6

101.2

19.2

161

2662

LG-SS3093-48

48

52.8

105.6

20

168

3010

200

LG-SS3093-50

50

55

110

20.8

175

3412

LG-SS3093-52

52

57.2

114.4

21.6

182

3813

216

LG-SS3093-54

54

59.4

118.8

22.5

189

4293

LG-SS3093-56

56

61.6

123.2

23.3

196

4772

232

LG-SS3093-58

58

63.8

127.6

24.2

203

5326

LG-SS3093-60

60

66

132

25

210

5880

248


Bulk Photos of Cable Ferrule Stainless Steel DIN 3093(EN 13411-3)

bulk photos of cable ferrule stainless steel din 3093en 13411 3
bulk photos of cable ferrule stainless steel din 3093en 13411 3 2
bulk photos of cable ferrule stainless steel din 3093en 13411 3 3
