High Test Eye Grab Hook Grade 43,also known as shortening grab hook.
A grab hook has a narrow throat allowing it to grab a link of the chain and prevent it from slipping, designed to allow chain to grab through the hook.
These sturdy hooks meet U.S. Federal Specification for toughness and durability.
Our range of Grade 70 Eye Grab hook is available in standard as well as customized sizes.
Technical Notes | U.S. Federal Specification |
Material | Superior Carbon Steel |
Safety Factor | 4: 1 |
Processing | Forged / Quenched and Tempered |
Finish | Powder Coated / Hot Dipped Galvanized / Electric Galvanized / Self-Color |
Size | 1/4”, 5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4” |
Tips | Finish: Customized according to customers’ requirements |
Part No. | Weight lbs | WLL (lbs) | R±1 | H±1 | D±0.5 | E±0.5 | L±1 |
(mm) | |||||||
LG-43-EGH-1/4 | 0.28 | 2600 | 50.5 | 18.5 | 13 | 9 | 77 |
LG-43-EGH-5/16 | 0.45 | 3900 | 56.8 | 22.7 | 14 | 11.5 | 89 |
LG-43-EGH-3/8 | 0.79 | 5400 | 65.2 | 28.3 | 17 | 13 | 104 |
LG-43-EGH-7/16 | 1.26 | 7200 | 77 | 33.5 | 20 | 15.5 | 122 |
LG-43-EGH-1/2 | 1.75 | 9200 | 85.5 | 37.5 | 22 | 17 | 135 |
LG-43-EGH-5/8 | 3.25 | 13000 | 116 | 45 | 30 | 21 | 180 |
LG-43-EGH-3/4 | 5.94 | 20200 | 133.5 | 55 | 35 | 25 | 211 |
Warning!!!
Do not exceed the working load limit.
Not to be used for overhead lifting.
Make sure the hook size and chain diameter are compatible before attaching to load.
Also available in Eye Grab Hook Grade 70.
