Name: Regular Nut Eye Bolts G-291 Stainless Steel-LG RIGGING®
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

Stainless Steel Products

 

Shade Sail Hardware 

Stainless Shackles 

Stainless Turnbuckle 

Stainless Eye Bolts & Nuts 

 Lifting Eye Bolt DIN 580 UNC Thread Stainless Steel

 Lifting Eye Nut DIN 582 UNC Thread Stainless Steel

 Stainless Steel Long Shank Eye Bolt with Nut and Washer

 Lifting Eye Bolt DIN 580 Stainless Steel

 Lifting Eye Nut DIN 582 Stainless Steel

 Stainless Steel Eye Bolt JIS 1168 Standard

 Stainless Steel Lifting Eye Nut JIS 1169 UNC Thread

 Stainless Steel Lifting Eye Nut JIS 1169

 Stainless Steel Shoulder Eye Bolt UNC Thread with Nut and Washer

 Stainless Steel Forged Shoulder Nut Eye Bolt G-277

 Regular Nut Eye Bolts G-291 Stainless Steel-LG RIGGING®

 Shoulder Type Machinery Eye Bolt Stainless Steel G-279

 Stainless Steel Lag Eye Bolt

 Stainless Steel Lag Eye Screw

 Stainless Steel Eye Bolt Unwelded

 Stainless Steel Swing Eye Bolt UNC Thread

 Stainless Steel Ring Eye Bolt

 Stainless Steel Welded Eye Bolt with Nut & Washer

 DIN444 Eye Swing Bolts Stainless Steel

Stainless Thimbles 

Stainless Rings 

Stainless Swivels 

Stainless Quick Link 

Stainless Wire Clips 

Stainless Hooks & Clips 

Stainless Terminals 

Stainless U Bolts 

Stainless Hinge 

Stainless Pulleys 

Drop Forged Stainless Products 

Stainless Chains 

Eye Plate, Eye Straps, Angles 

Boat Fittings

 

Pole Line Hardware

 

Information of Regular Nut Eye Bolts G-291 Stainless Steel–China LG™

Technical Notes	Regular Nut Eye bolt Conform to G-291 US.FED.SPEC.
Material	Stainless Steel 304 or 316 Regular Nut Eye Bolt
Processing	Precision Cast
Finish	Machine Polishing /Electrolytic Polishing
Size	1/4”, 5/16”, 3/8″, 1/2”, 5/8″, 3/4″, 7/8″, 1″, 1-1/4″, 1-1/2″ Eye Bolt UNC Thread

Specifications of Regular Nut Eye Bolts G-291 Stainless Steel–China LG™

Part No.	Shank Dia & Length (in)	Working Load Limit (lbs)	Weight Per 100 (lbs)	Dimensions (in)
Part No.	Shank Dia & Length (in)	Working Load Limit (lbs)	Weight Per 100 (lbs)	A	B	C	D	E	F	G	H
LGSS291EB101	1/4 x 2”	500	8.2	0.25	0.5	1	0.25	1.5	2	3.06	0.56
LGSS291EB102	1/4 x 4”	500	11.7	0.25	0.5	1	0.25	2.5	4	5.06	0.56
LGSS291EB103	5/16 x 2 1/4”	800	13.3	0.31	0.62	1.25	0.31	1.5	2.25	3.56	0.69
LGSS291EB104	5/16 x 4 1/4”	800	25	0.31	0.62	1.25	0.31	2.5	4.25	5.56	0.69
LGSS291EB105	3/8 x 2 1/2”	1200	23.3	0.38	0.75	1.5	0.38	1.5	2.5	4.12	0.88
LGSS291EB106	3/8 x 4 1/2”	1200	29.5	0.38	0.75	1.5	0.38	2.5	4.5	6.12	0.88
LGSS291EB107	3/8 x 6”	1200	35.2	0.38	0.75	1.5	0.38	2.5	6	7.62	0.88
LGSS291EB108	1/2 x 3 1/4”	2200	50.3	0.5	1	2	0.5	1.5	3.25	5.38	1.12
LGSS291EB109	1/2 x 6”	2200	66.1	0.5	1	2	0.5	3	6	8.12	1.12
LGSS291EB110	1/2 x 8”	2200	82	0.5	1	2	0.5	3	8	10.12	1.12
LGSS291EB111	1/2 x 10”	2200	88	0.5	1	2	0.5	3	10	12.12	1.12
LGSS291EB112	1/2 x 12”	2200	114.2	0.5	1	2	0.5	3	12	14.12	1.12
LGSS291EB113	1/2 x 15”	2200	116.85	0.5	1	2	0.5	4	15	17.12	1.12
LGSS291EB114	5/8 x 4”	3500	103.1	0.62	1.25	2.5	0.62	2	4	6.69	1.44
LGSS291EB115	5/8 x 6”	3500	118.2	0.62	1.25	2.5	0.62	3	6	8.69	1.44
LGSS291EB116	5/8 x 8”	3500	135.1	0.62	1.25	2.5	0.62	3	8	10.69	1.44
LGSS291EB117	5/8 x 10”	3500	153.6	0.62	1.25	2.5	0.62	3	10	12.69	1.44
LGSS291EB118	5/8 x 12”	3500	167.1	0.62	1.25	2.5	0.62	4	12	14.69	1.44
LGSS291EB119	5/8 x 15”	3500	201.16	0.62	1.25	2.5	0.62	5	15	17.69	1.44
LGSS291EB120	5/8 x 24”	3500	279.1	0.62	1.25	2.5	0.62	6	24	26.69	1.44
LGSS291EB121	3/4 x 4 1/2”	5200	168.6	0.75	1.5	3	0.75	2	4.5	7.69	1.69
LGSS291EB122	3/4 x 6”	5200	184.5	0.75	1.5	3	0.75	3	6	9.19	1.69
LGSS291EB123	3/4 x 8”	5200	207.9	0.75	1.5	3	0.75	3	8	11.19	1.69
LGSS291EB124	3/4 x 10”	5200	235	0.75	1.5	3	0.75	3	10	13.19	1.69
LGSS291EB125	3/4 x 12”	5200	257.5	0.75	1.5	3	0.75	4	12	15.19	1.69
LGSS291EB126	3/4 x 15”	5200	298	0.75	1.5	3	0.75	5	15	18.19	1.69
LGSS291EB127	7/8 x 5”	7200	270	0.88	1.75	3.5	0.88	2.5	5	8.75	2.00
LGSS291EB128	7/8 x 8”	7200	308	0.88	1.75	3.5	0.88	4	8	11.75	2.00
LGSS291EB129	7/8 x 12”	7200	400	0.88	1.75	3.5	0.88	4	12	15.75	2.00
LGSS291EB130	1 x 6”	10000	421	1	2	4	1.00	3	6	10.31	2.31
LGSS291EB131	1 x 9”	10000	468.5	1	2	4	1.00	4	9	13.31	2.31
LGSS291EB132	1 x 12”	10000	540	1	2	4	1.00	4	12	16.31	2.31
LGSS291EB133	1 x 18”	10000	650	1	2	4	1.00	7	18	22.31	2.31
LGSS291EB134	1 1/4 x 8”	15200	750	1.25	2.5	5	1.25	4	8	13.38	2.88
LGSS291EB135	1 1/4 x 12”	15200	900	1.25	2.5	5	1.25	4	12	17.38	2.88
LGSS291EB136	1 1/4 x 20”	15200	1210	1.25	2.5	5	1.25	6	20	25.38	2.88
