Shoulder Type Machinery Eye Bolt Stainless Steel G-279

Shoulder Type Machinery Eye Bolt G-279 Stainless Steel US Type,also known as machinery eye bolts with shoulder.

These Stainless Steel lifting Eye Bolt G279 are with shoulder. Eye bolts are fully threaded with standard “UNC” thread. Rod is threaded and welded into precision cast eye nuts.

This shoulder type machinery eye bolt G-279, made from Stainless steel 304 or 316, which has superior corrosion resistance, the technical processing is cast, and after highly polishing,the surface looks great.

We manufacture lifting eye in regular sizes. Apart from this, we can also custom manufacture a wide range of eye bolts, available in forged, carbon steel, stainless steel and self colored size and coating.

Shoulder pattern machinery eye bolt G279 are used for lifting equipment that has pre-tapped holes. These eye bolts simply thread into the hole, which is why they are not shipped with nuts.

Stainless Steel Shoulder Eye Bolts G279 are hugely popular within the marine industry. Their material is stainless steel giving them the best rust protection.

Trawling Gear
Shackles
Boat Fittings

Information of Shoulder Type Machinery Eye Bolt Stainless Steel G-279

Technical Notes

Lifting Eye bolt Conform to G-279 US.FED.SPEC.

Material

Stainless Steel 304 or 316 machine Eye Bolt

Processing

Precision Cast

Finish

Machine Polishing /Electrolytic Polishing

Size

1/4”, 5/16”, 3/8″, 1/2”, 5/8″, 3/4″, 7/8″, 1″, 1-1/4″, 1-1/2″ Eye Bolt UNC Thread


Specifications of Shoulder Type Machinery Eye Bolt Stainless Steel G-279

Specifications of Shoulder Type Machinery Eye Bolt Stainless Steel G-279


Part No.

D1

L

B

Min.BL

(Lbs)

LG-SS-EB-279-01

1/4”

1″

0.75

2300

LG-SS-EB-279-02

5/16”

1-1/8”

0.88

3650

LG-SS-EB-279-03

3/8″

1-1/4″

1.00

5200

LG-SS-EB-279-04

1/2”

1-1/2″

1.19

9150

LG-SS-EB-279-05

5/8″

1-3/4*

1.38

14000

LG-SS-EB-279-06

3/4″

2″

1.50

21000

LG-SS-EB-279-07

7/8″

2-1/4″

1.75

28000

LG-SS-EB-279-08

1″

2.1/2″

2.00

36500

LG-SS-EB-279-09

1-1/4″

3”

2.50

57500

LG-SS-EB-279-10

1-1/2″

3-1/2″

3.00

82500


Please note we supply a huge variety of stainless steel parts.

We are a professional manufacturer and supplier of Trawling / Rigging / Stainless / Yacht Equipments in China
