Screw Pin Anchor Shackle U.S. Type

Screw Pin Anchor Shackle U.S. Type, also known as bow shackle screw pin.

Anchor shackle screw pin conform to US FED SPEC, it's G209, featured oversized screw pin.

This screw pin bow shackle, shackle body made from superior carbon steel, screw pin made from alloy steel or carbon steel.

have a large rounded shape that allows them to take loads from many directions without developing significant side load. That makes them ideal for use with multiple-leg slings, connecting slings to load rings, and accommodating a wider strap.

The screw pin configuration is best for use in applications that are temporary, or require repeated or quick connections and disconnections.

Working load Limit from 1/2 Ton to 55 Ton are available in grades 4 and 6, with grade 4 meaning that the breaking load is 4 times the working load limit and grade 6 meaning that the breaking load is 6 times the working load limit.

Trawling Gear
Shackles
Boat Fittings

Information of Screw Pin Anchor Shackle U.S. Type

Technical Notes

Anchor shackle conform to U.S. Federal Specification(ASME B30.26)

Material

Body: Superior Carbon Steel

Screw Pin: Alloy Steel / Superior Carbon Steel

Safety Factor

6 : 1   /   4 : 1

Processing

Body: Drop Forged / Quenched and Tempered

Screw Pin : hot/cold forging / Drop Forged / Quenched and Tempered

Finish

Body: Hot Dipped Galvanized / Powder Coated / Zinc Plated

Screw Pin: Powder Coated / Zinc Plated

Size

3/16”, 1/4”, 5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4”, 7/8”, 1”, 1-1/8”, 1/1/4”, 1-3/8”, 1-1/2”, 1-3/4”, 2”, 2-1/2” anchor shackle screw pin

Tips

Special specification and marks can be made according to customers’ requirements


Specifications of Screw Pin Anchor Shackle U.S. Type

Specifications of Screw Pin Anchor Shackle G-209 U.S. Type


Part No.

Size

WLL

Weight

Dimensions (in.)

Tolerance +/-

(in.)

(t)

(lbs)

A

B

C

E

G

H

P

C

A

LG-209-SPBS-3/16

3/16

1/3

0.06

0.38

0.25

0.88

0.6

0.98

1.47

0.19

0.06

0.06

LG-209-SPBS-1/4

1/4

1/2

0.1

0.47

0.31

1.13

0.78

1.28

1.84

0.25

0.06

0.06

LG-209-SPBS-5/16

5/16

3/4

0.19

0.53

0.38

1.22

0.84

1.47

2.09

0.31

0.06

0.06

LG-209-SPBS-3/8

3/8

1

0.31

0.66

0.44

1.44

1.03

1.78

2.49

0.38

0.13

0.06

LG-209-SPBS-7/16

7/16

1-1/2

0.38

0.75

0.5

1.69

1.16

2.03

2.91

0.44

0.13

0.06

LG-209-SPBS-1/2

1/2

2

0.72

0.81

0.63

1.88

1.31

2.31

3.28

0.5

0.13

0.06

LG-209-SPBS-5/8

5/8

3-1/4

1.37

1.06

0.75

2.38

1.69

2.94

4.19

0.69

0.13

0.06

LG-209-SPBS-3/4

3/4

4-3/4

2.35

1.25

0.88

2.81

2

3.5

4.97

0.81

0.25

0.06

LG-209-SPBS-7/8

7/8

6-1/2

3.62

1.44

1

3.31

2.28

4.03

5.83

0.97

0.25

0.06

LG-209-SPBS-1/1

1

8-1/2

5.03

1.69

1.13

3.75

2.69

4.69

6.56

1.06

0.25

0.06

LG-209-SPBS-1-1/8

1-1/8

9-1/2

7.41

1.81

1.25

4.25

2.91

5.16

7.47

1.25

0.25

0.06

LG-209-SPBS-1-1/4

1/1/4

12

9.5

2.03

1.38

4.69

3.25

5.75

8.25

1.38

0.25

0.06

LG-209-SPBS-1-3/8

1-3/8

13-1/2

13.53

2.25

1.5

5.25

3.63

6.38

9.16

1.5

0.25

0.13

LG-209-SPBS-1-1/2

1-1/2

17

17.2

2.38

1.63

5.75

3.88

6.88

10

1.62

0.25

0.13

LG-209-SPBS-1-3/4

1-3/4

25

27.78

2.88

2

7

5

8.86

12.34

2.25

0.25

0.13

LG-209-SPBS-2/1

2

35

45

3.25

2.25

7.75

5.75

9.97

13.68

2.4

0.25

0.13

LG-209-SPBS-2-1/2

2-1/2

55

85.75

4.13

2.75

10.5

7.25

12.87

17.84

3.13

0.25

0.25
