Stainless Steel Turnbuckle Jaw & Jaw, US Spec.

  • Description

Stainless Steel Turnbuckle Jaw & Jaw, US Spec. – China LG Supply





Description

Stainless Steel Turnbuckle Jaw & Jaw, US Spec., also known as  Straining Screws, Open Body Barrel Strainers or Turnbuckles, feature a hex turnbuckle body with clevis jaws at each end, to provide a combination of the easy attachment like a Hook and Hook Turnbuckle but with the security of a closed connection like an Eye and Eye Turnbuckle.

Jaw and jaw turnbuckle stainless steel meet dimensions of ASTM specification F1145-92 Type 1, Class H.

Our stainless steel turnbuckle jaw and jaw turnbuckle, made of marine grade stainless steel AISI304/316, been forged / casted, conform to US Federal specification. very durable and corrosion resistance.





Technical & Application

Technical Notes

Turnbuckle conform to US Federal Specification(ASTM F1145-92)
Material

Stainless steel (AISI 304/AISI 316)

Size

1/4×4” , 5/16×4.5” , 3/8×6” , 1/2×6” , 1/2×9” , 1/2×12” , 5/8×6” , 5/8×9” , 5/8×12”

3/4×6” , 3/4×9” , 3/4×12” , 7/8×6” , 7/8×12” , 1×6” , 1×12” , 1-1/4×12” , 1-1/2×12”

Processing

Cast / Forged

Finish

Highly Polishing
Tips

Corrosion Resistant





Specification

Stainless Steel Turnbuckle Jaw & Jaw, US Spec.-China supplier manufacturer

Item No.

SizeLL1ADBH

in.

LG-SS-US-T-JJ-1/4×4

1/447.150.450.240.90.62
LG-SS-US-T-JJ-5/16×4.55/164.58.610.490.241

0.87

LG-SS-US-T-JJ-3/8×6

3/8610.450.530.311.080.87
LG-SS-US-T-JJ-1/2×61/2611.880.670.391.36

1.06

LG-SS-US-T-JJ-1/2×9

1/2914.880.670.391.361.06
LG-SS-US-T-JJ-1/2×121/21217.880.670.391.36

1.06

LG-SS-US-T-JJ-5/8×6

5/8613.30.810.471.681.31
LG-SS-US-T-JJ-5/8×95/8916.30.810.471.68

1.31

LG-SS-US-T-JJ-5/8×12

5/81219.30.810.471.681.31
LG-SS-US-T-JJ-3/4×63/4614.621.020.631.97

1.5

LG-SS-US-T-JJ-3/4×9

3/4917.621.020.631.971.5
LG-SS-US-T-JJ-3/4×123/41220.621.020.631.97

1.5

LG-SS-US-T-JJ-7/8×6

7/86161.180.792.431.75
LG-SS-US-T-JJ-7/8×127/812221.180.792.43

1.75

LG-SS-US-T-JJ-1×6

1617.61.30.872.632.06
LG-SS-US-T-JJ-1×1211223.61.30.871.3

2.06

LG-SS-US-T-JJ-1-1/4×12

1-1/41226.461.831.123.62.81
LG-SS-US-T-JJ-1-1/2×121-1/21227.882.051.383.96

2.81


Pre-Caution:
 Never exceed the working load limit ( WLL)





Details – Stainless Steel Turnbuckle Jaw & Jaw, US Spec.
