Name: Stainless Steel Forged Shoulder Nut Eye Bolt G-277
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

Stainless Steel Products

 

Stainless U Bolts 

Stainless Thimbles 

Stainless Terminals 

Stainless Swivels 

Stainless Hinge 

Stainless Shackles 

Stainless Rings 

Stainless Quick Link 

Stainless Pulleys 

Stainless Hooks & Clips 

Stainless Wire Clips 

Shade Sail Hardware 

Drop Forged Stainless Products 

Stainless Turnbuckle 

Stainless Chains 

Stainless Eye Bolts & Nuts 

 Lifting Eye Bolt DIN 580 UNC Thread Stainless Steel

 Lifting Eye Nut DIN 582 UNC Thread Stainless Steel

 Stainless Steel Long Shank Eye Bolt with Nut and Washer

 Lifting Eye Bolt DIN 580 Stainless Steel

 Lifting Eye Nut DIN 582 Stainless Steel

 Stainless Steel Eye Bolt JIS 1168 Standard

 Stainless Steel Lifting Eye Nut JIS 1169 UNC Thread

 Stainless Steel Lifting Eye Nut JIS 1169

 Stainless Steel Shoulder Eye Bolt UNC Thread with Nut and Washer

 Stainless Steel Forged Shoulder Nut Eye Bolt G-277

 Regular Nut Eye Bolts G-291 Stainless Steel-LG RIGGING®

 Shoulder Type Machinery Eye Bolt Stainless Steel G-279

 Stainless Steel Lag Eye Bolt

 Stainless Steel Lag Eye Screw

 Stainless Steel Eye Bolt Unwelded

 Stainless Steel Swing Eye Bolt UNC Thread

 Stainless Steel Ring Eye Bolt

 Stainless Steel Welded Eye Bolt with Nut & Washer

 DIN444 Eye Swing Bolts Stainless Steel

Eye Plate, Eye Straps, Angles 

Boat Fittings

 

Pole Line Hardware

 

Information of Stainless Steel Forged Shoulder Nut Eye Bolt G-277

Technical Notes	US.FED.SPEC. G-277 Eye Bolt
Material	Stainless Steel 304 or 316 Eye Bolt
Processing	Precision Cast
Finish	Machine Polishing / Electrolytic Polishing
Size	1/4″, 5/16″, 3/8″, 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1-1/4″ eye bolt UNC Thread
Tips	With Nut and Washer.

Specifications of Stainless Steel Forged Shoulder Nut Eye Bolt G-277

Part No.	D1	L	B	Min.BL
Part No.	D1	L	B	(Lbs)
LG-SS-EB-277-01	1/4”	2.00′	0.50″	2300
LG-SS-EB-277-02	1/4″	4.00′	0.50″	2300
LG-SS-EB-277-03	5/16″	2.25*	0.62″	3650
LG-SS-EB-277-04	5/16″	4.50*	0.62″	3650
LG-SS-EB-277-05	3/8“	2.50,	0.75″	5200
LG-SS-EB-277-06	3/8″	4.50*	075″	5200
LG-SS-EB-277-07	1/2”	3,25,	1.00″	9150
LG-SS-EB-277-08	1/2″	6,00′	1,00”	9150
LG-SS-EB-277-09	5/8”	4,00′	1.25′	14000
LG-SS-EB-277-10	5/8″	6,00′	1.25″	14000
LG-SS-EB-277-11	3/4″	4,50”	1.50″	21000
LG-SS-EB-277-12	3/4″	6,00°	1,50″	21000
LG-SS-EB-277-13	7/8″	5,00,	1.75-	28000
LG-SS-EB-277-14	1″	6,00*	2.00″	36500
LG-SS-EB-277-15	1″	9,00”	2.00″	36500
LG-SS-EB-277-16	1,1/4”	8.00″	2.50″	57500
LG-SS-EB-277-17	1,1/4″	12.00″	2.50″	57500
