Wire Rope Puller in Steel WPS Type–LG Rigging®

Wire Rope Puller in Steel WPS Type – China LG™, also known as wire rope pulling hoist, and this one is Aluminium body.

Wire Rope Pulling Hoist WPS Type, made from steel, has the same performance as aluminum alloy steel cable puller, currently there are 0.8T, 1.6T, 3.2T three specifications.

China LG Supply on the shelf of this wire rope puller is China’s only a new model. Fully independent research and development and innovation. Compared with aluminum wire rope hand hoist, it has higher strength and is more convenient to use. Especially in some special environment (blasting, mining machine) can reflect its advantages.

Lever hoist is a kind of manual lifting tool which is portable and easily to use.

Manual cable puller can be used in various operations like lifting, towing , drops and calibration,and which is widely used in shipbuilding, electric power, transportation, construction, mining, telecommunications and other industry.

Rope lever hoist will raise your working efficiency.

Wire rope pullers is a kind of small-sized, compact, new design, hand-operated lifting tool for pulling, lifting, lowering wire ripe pulling hoist is widely suitable for use in drawing or lifting heavy goods under all kinds of circumstances, especially suitable for using in installation and fix in industry.

Lever wire rope hoist also named Wire rope lever hoist feature a lightweight, compact, high strength aluminum housing, smooth contour design with a large, flat bottom surface for increased stability in horizontal and vertical working positions.


Features

1. Compared with aluminum wire rope hand hoist, it has higher strength and is more convenient to use. Especially in some special environment (blasting, mining machine) can reflect its advantages.
2. Equipped with two safty devices, and this guarantees safe operations.
3. Wire rope is drawn out straight, by distant operations regardless of wire lengths.
4. Transmission at a sppeed of 3 meters per minute, and this is the fasteset speed among all hand-driven handling devices.
5. Wire rope can be used at any working temperature degrees.
6. Equipped with a saftey hook, preventing wire rope from coming off while operation.
7. Most rationally peaneed, designed and duarble.

Trawling Gear
Shackles
Boat Fittings

Information of Wire Rope Puller in Steel WPS Type–China LG™

Chassis

Cold rolled steel sheet made of stamping, high strength.

Shell surface treatment

Spray, Chrome plated. standard for sand gray, color can be customized

jaw blocks

Using 40Cr Suitable hardness after quenching, That does not damage the wire rope and can ensure safety

Wire rope

Hot dip galvanized, Structure 6xl9W+IWR, The standard 20 meters, Strength 1770Mpa, length can be customized

Wire rope hook

Standard American eye hook, material 35CrMo, high tensile strength.Swivel hook or European hook can be used as required


Specifications of Wire Rope Puller in Steel WPS Type–China LG™

Part No.

Lifting


Capacity

(Rated Load)

Pulling


Capacity

Lever Pull


at rated Load

Forward


Travel

Wire Rope


Diameter

Net


Weight (Body)

Net Weight


(20 m Wire Rope)

Weight


(Lever Handle)

Dimensions (Body)


L x W x H

(tonnes)

(N)

(mm)

(kg)

(mm)

LGWPS0.8T

0.8

1.2

284

>52

8.3

6.8

6.5

1.3

440 x 70 x 255

LGWPS1.6T

1.6

2.4

412

>55

11

12.8

10.5

23

560 x 100 x 295

LGWPS3.2T

3.2

4

441

>28

16

23.4

22

2.3

675 x 120 x 350


Bulk Photos of Wire Rope Puller in Steel WPS Type–China LG™

bulk photos of wire rope puller in steel wps typechina lg
