Name: LGRIG® Stainless Steel 45 Degree Rectangular Base Rail Fitting
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

Stainless Steel Products

 

Boat Fittings

 

Stainless Marine Hinges 

Bimini Top Fittings 

Cleats & Fairleads 

Angle Bracket 

Rail Fittings 

 LGRIG® Stainless Steel 45 Degree Round Base Rail Fitting

 Stainless Steel Flat Tube Holder-China LG Manufacture

 Stainless Steel Vertical Tube Holder-China LG Manufacture

 Stainless Steel Tube Joint Ringed Fast Pin

 60 Degree Stainless Steel Split Tee-China LG Manufacture

 Stainless Steel Boat Rectangular Base 60 Degree-LG RIGGING®

 90 Degree Stainless Steel Split Tee-China LG Manufacture

 Stainless Steel Boat Handrail Rectangular Base 90 Degree-China

 60 Degree Stainless Steel Tee-China LG Manufacture

 Top Boat Flag Pole Socket 60 Degrees-China LG Manufacture

 90 Degree Stainless Steel Handrail Tee-China LG Supply

 Top Boat Flag Pole Socket 30 Degrees-China LG Manufacture

 Stainless Steel 4 Way Corner Tee Fitting-China LG Supply

 Top Boat Flag Pole Socket 90 Degrees-China LG Manufacture

 Stainless Steel 3 Way Corner Tee Fitting-China LG Supply

 Boat Hand Rail Fitting 90 Degree-China LG Manufacture

 LGRIG® Stainless Steel Forward Handrail Stanchion 60 Degree

 LGRIG® Stainless Steel Center Handrail Stanchion 60°

 LGRIG® 316 Stainless Steel Aft Handrail Fitting 60°

 LGRIG® Nylon Single-Tube Fishing Rod Holder

 LGRIG® Nylon Double-Tube Fishing Rod Holder

 LGRIG® Nylon 3-Tube Fishing Rod Holder

 LGRIG® 4-Tube Fishing Rod Holder

 LGRIG® Adjustable Waist Fishing Rod Holder

 LGRIG® Stainless Steel Rectangular Base Rail Fitting 30 Degree

 LGRIG® Stainless Steel 45 Degree Rectangular Base Rail Fitting

Thru-Hull & Deck Fittings 

Stainless Latches 

Mooring Compensators / Springs 

Brake Lining 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Stainless Steel 45 Degree Rectangular Base Rail Fitting

Brand	LGRIG®
Product Name	316 Stainless Steel 45° Rectangular Base Rail Fitting
Common Name	45° Rectangular Base Rail Fitting
Product Type	Marine Rail Fitting / Handrail Base Fitting
Material	316 Stainless Steel*
Surface	High Polished / Mirror Polished
Angle	45°
Base Type	Rectangular Base
Tube Type	Round Tube / Round Rail
Tube Size	7/8" (22 mm), 1" (25 mm)
Features	Corrosion Resistant, Durable, Strong, Stable Mounting
Mounting Type	Deck / Surface Mount
Mounting Holes	Multiple Countersunk Mounting Holes
Installation	Screw/Fastener Mounting
Use	Connecting Round Rail or Handrail to Deck
Application	Boat Handrails, Yacht Railings, Guard Rails, Bimini Structures
Suitable For	Boats, Yachts, Cruisers, Fishing Boats, Pontoons
Marine Application	Yes
Origin	China

Specification of LGRIG® Stainless Steel 45 Degree Rectangular Base Rail Fitting


Part No.	SIZE	A	B	C	D	E	F	G	H	K	M	Weight(KG)
LGSSB45RT22	7/8" (22mm)	77.0	44.0	38.0	22.8	29.5	62.5	45°	5.0	5.5	M6	0.140
LGSSB45RT25	1" (25mm)	82.0	47.0	38.0	25.8	30.0	65.0	45°	5.0	6.5	M6	0.150
