Information of LGRIG® Drop Forged Stainless Steel Hammerlock Chain Connector European Type

Brand	LGRIG®
Standard	Hammerlock chain connector meet to European Type
Material	Stainless steel 304 or 316 Connector
Processing	Drop Forged
Finish	Polishing
Size	6mm, 7mm, 7/8mm，8mm, 10mm, 13mm, 16mm, 18mm, 20mm, 22mm, 26mm, 32mm
Country of Origin	China

Specifications of LGRIG® Drop Forged Stainless Steel Hammerlock Chain Connector European Type


Part No.	Size	Weight (kg)	Woring Load Limit (t)	Breaking Load (t)	A±1.5	B±1	L±2.5	K±2	H±1
LGSSCLEU6	6	0.08	1.12	2.8	15	7.5	58	42	7
LGSSCLEU7	7	0.145	1.5	3.75	19	8.5	71.8	54.8	8.5
LGSSCLEU7/8	7/8	0.146	2	5	18	9.5	79.5	60.5	8.5
LGSSCLEU8	8	0.16	2	5	19.5	9.5	79.5	60.5	8.5
LGSSCLEU10	10	0.3	3.15	7.875	25	12	90.5	68	11.5
LGSSCLEU13	13	0.65	5.4	13.25	29	15	117	87	15
LGSSCLEU16	16	1.15	8	20	34.5	19.8	148	108.4	19.8
LGSSCLEU18	18	1.84	10	25	38	21	154	112	21
LGSSCLEU20	20	2.1	12.5	31.25	41	24	169.5	121.5	24
LGSSCLEU22	22	2.87	15	37.5	48	26	193.5	141.5	26
LGSSCLEU26	26	4.5	21.2	53	57.5	31	220	158	30
LGSSCLEU32	32	8.21	31.5	78.75	67	38	281	205	37
