Stainless Steel Shoulder Eye Bolt UNC Thread with Nut and Washer

Stainless Steel Shoulder Eye Bolt, also known as shoulder eye bolt, fitted with nut and washer.

Shoulder eye bolts stainless steel, made from marine grade stainless steel 304 or 316, which is often used in marine applications for its increased resistance to chloride corrosion.

However, stainless steel long shank eye bolt‘s strength and corrosion protection also makes them desirable for a wide range of environments.

Long shank shoulder eye bolt can be used for either straight line or angular pulls.

Stainless steel long shank lifting eye bolt, with a UNC thread 1/4″, 5/16″, 3/8″, 1/2″, 5/8″, 3/4″, 7/8″.

Trawling Gear
Shackles
Boat Fittings

Information of Stainless Steel Shoulder Eye Bolt UNC Thread with Nut and Washer

Material

Stainless Steel 304/316 long shank eye bolt

Processing

Hot Upsetting

Finish

High Polished

Size

1/4″, 5/16″, 3/8″, 1/2″, 5/8″, 3/4″, 7/8″ shoulder eye bolt

Tips

Including eyebolts, nut and washer.

Notes

Any length of screw available.


Specifications of Stainless Steel Shoulder Eye Bolt UNC Thread with Nut and Washer

Specifications of Stainless Steel Shoulder Eye Bolt UNC Thread with Nut and Washer


Part No.

D1

L

D

B

Min.BL

lbs

LG-SS-EB-S-UNC-01

1/4″

1.57″

0.197″

0.59″

2300

LG-SS-EB-S-UNC-02

1/4″

2.00″

0.197″

0.59″

2300

LG-SS-EB-S-UNC-03

1/4″

2.36″

0.197″

0.59″

2300

LG-SS-EB-S-UNC-04

5/16″

2.36″

0.236″

0.79″

3650

LG-SS-EB-S-UNC-05

5/16″

4.00″

0.236″

0.79″

3650

LG-SS-EB-S-UNC-06

3/8″

3.15″

0.315″

1.00″

5200

LG-SS-EB-S-UNC-07

3/8″

4.00″

0.315″

1.00″

5200

LG-SS-EB-S-UNC-08

3/8″

5.00″

0.315″

1.00″

5200

LG-SS-EB-S-UNC-09

3/8″

6.00″

0.315″

1.00″

5200

LG-SS-EB-S-UNC-10

1/2″

1.57″

0.394″

1.18″

9150

LG-SS-EB-S-UNC-11

1/2″

3.15″

0.394″

1.18″

9150

LG-SS-EB-S-UNC-12

1/2″

4.00″

0.394″

1.18″

9150

LG-SS-EB-S-UNC-13

1/2″

6.00″

0.394″

1.18″

9150

LG-SS-EB-S-UNC-14

5/8″

1.77″

0.472″

1.38″

14000

LG-SS-EB-S-UNC-15

5/8″

6.00″

0.472″

1.38″

14000

LG-SS-EB-S-UNC-16

3/4″

6.00″

0.590″

1.57″

21000

LG-SS-EB-S-UNC-17

3/4″

12.00″

0.590″

1.57″

21000

LG-SS-EB-S-UNC-18

7/8″

9.00″

0.710″

1.57″

21000


Please Note:
Loading at an angle will significantly reduce a bolt’s rated capacity; a 45 degree angle reduces it to just 1/4 of the stated rating. Never load at an angle greater than 45 degrees from the bolt center line.

Bulk Photos of Stainless Steel Shoulder Eye Bolt UNC Thread with Nut and Washer

bulk photos of stainless steel shoulder eye bolt unc thread with nut and washer
