The Synthetic Rope Thimble provides a new dimension in light weight heavy-duty rope thimbles with this improved desigh for use in the marine towing industry. Light enough for easy handling, but with the maximum strength at critical points. The generous inside dimensions allow these thimbles to fit any large towing shackle or any large regular shackle.
For use with all types of synthetic rope. Larger sizes have rope retaining rings. Injection molded from tough, wear-resistant polyallomer material. ideal for use with lanyards, hand lines, mooring lines.
Material | Super Carbon Material |
Processing | Cast |
Finish | Zinc plated, Hot dipped galvanized |
Size | Ø16/Φ22,Ø24/Φ30,Ø32/Φ40,Ø44,Ø48/Φ56 Ø64,Ø72,Ø80,Ø88/Ø96,Ø112 |
Part No. | ROPE DIAMETER (mm) | A | B | C | D | E | F | G | WEIGHT(kg) APPROX |
LG-SRT-01 | Ø16/Ø22 | 111.5 | 65 | 32 | 10 | 37 | 28 | 35 | TBA |
LG-SRT-02 | Ø24/Ø30 | 146.5 | 90 | 51 | 28 | 47 | 37 | 40 | 1.25 |
LG-SRT-03 | Ø32/Ø40 | 196 | 127 | 85 | 42 | 57 | 46 | 50 | 2.25 |
LG-SRT-04 | Ø44 | 205 | 140 | 86 | 42 | 64 | 52 | 54 | 3.40 |
LG-SRT-05 | Ø48/Ø56 | 247 | 149 | 92 | 44 | 85 | 70 | 76 | 5.30 |
LG-SRT-06 | Ø64 | 274.5 | 159 | 102 | 54 | 95 | 76 | 79 | 7.90 |
LG-SRT-07 | Ø72 | 316 | 194 | 120 | 68 | 102 | 83 | 89 | 12.25 |
LG-SRT-08 | Ø80 | 349 | 217.5 | 127 | 70 | 108 | 89 | 98 | 14.45 |
LG-SRT-09 | Ø88/Ø96 | 403.5 | 241 | 156 | 86 | 140 | 114 | 117 | 26.40 |
LG-SRT-10 | Ø112 | 477.5 | 280 | 184 | 104 | 170 | 140 | 145 | 30 |
