Name: G80 Webbing Connecting Link Web Sling Connector
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

 G80 Hooks

 G80 Lifting Points

 G80 Links, Rings

 G80 Swivels

 G80 Other Products

Turnbuckles 

Shackles 

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Information of G80 Webbing Connecting Link Web Sling Connector

Material	Superior Alloy steel
Processing	Drop Forged, Quenched and Tempered
Finish	Powder Coated
Size	6mm, 8mm, 10mm, 13mm, 16mm, 20mm, 22mm, 26mm, 32mm
Safety Factor	4:1
Notes	Used to connect webbing slings to lifting components.

Specifications of G80 Webbing Connecting Link Web Sling Connector

Part No.	Size (mm)	Dimensions (in)						W.L.L. (T)	Weight (LBS)
Part No.	Size (mm)	A	B	K	W	G	E	W.L.L. (T)	Weight (LBS)
8-LG-WCL-01	6	0.6	2.36	2.2	1.57	0.71	0.3	1.12	0.44
8-LG-WCL-02	8	0.76	2.42	2.56	1.57	0.95	0.35	2	0.66
8-LG-WCL-03	10	0.98	2.95	3.03	1.61	1.18	0.46	3.15	1.5
8-LG-WCL-04	13	1.18	3.56	3.69	2.17	1.42	0.61	5.3	3.24
8-LG-WCL-05	16	1.42	4.63	4.72	2.58	1.78	0.75	8	5.07
8-LG-WCL-06	20	1.65	5.08	5.43	3.15	2.04	0.91	12.5	7.27
8-LG-WCL-07	22	1.93	7.52	7.09	4.96	2.76	0.96	15	15.17
8-LG-WCL-08	26	2.3	8.99	8.25	5.98	3.23	1.24	21.2	23.39
8-LG-WCL-09	32	2.66	9.92	10.98	6.3	3.58	1.52	31.5	41.67
