Information of G80 Lifting Screw Points Forged Alloy Steel

Material	G80 Lifting Point made of alloy steel
Processing	Drop Forged
Finish	Powder Coated
Size – Thread	G80 Lifting Screw Point size available in M8x13, M10x18, M10x90, M12x18, M12x40, M12x45, M12x110, M14x20, M16x35, M16x40, M16x100, M16x120 M20x30, M20x120, M24x40, M24x40, M24x90, M24x120, M27x35, M30x35, M30x38, M30x120, M30x35, M30x38, M30x120, M36x90, M36x400, M39x50, M39x90 M42x50, M42x60, M42x130, M42x180, M45x60, M48x50, M48x110, M56x84, M64x95

Specifications of G80 Lifting Screw Points Forged Alloy Steel

Part No.	Size (in)	W.L.L (t) (4:1)		Dimension (mm)
Part No.	Size (in)	WLL 0°	WLL 90°	DxE	B	C	G	T	A	W	N	H	S
8-LG-LP-8×13	M8	0.6	0.3	M8x13	36	16.5	51	41	55	30	14	3	1
8-LG-LP-10×18	M10	0.9	0.5	M10x18	36	16.5	51	41	55	30	14	3	1
8-LG-LP-10×90	M10x90	1	0.5	M10x90	36	16.5	51	41	55	30	14	3	1
8-LG-LP-12×18	M12	1	0.5	M12x18	36	16.5	51	41	55	30	14	3	1
8-LG-LP-12×40	M12x40	1	0.5	M12x40	36	16.5	51	41	55	30	14	3	1
8-LG-LP-12×45	M12x45	1	0.5	M12x45	36	16.5	51	41	55	30	14	3	1
8-LG-LP-12×110	M12x110	1	0.5	M12x110	36	16.5	51	41	55	30	14	3	1
8-LG-LP-14×20	M14	2	1.12	M14x20	36	16.5	52	42	55	30	14	3	1
8-LG-LP-16×35	M16	2	1.12	M16x35	36	16.5	52	42	55	30	14	3	1
8-LG-LP-16×40	M16x40	2	1.12	M16x40	36	16.5	52	42	55	30	14	3	1
8-LG-LP-16×100	M16x100	2	1.12	M16x100	36	16.5	52	42	55	30	14	3.5	1
8-LG-LP-16×120	M16x120	2	1.12	M16x120	36	16.5	68	56	70	35	16	3.5	1
8-LG-LP-20×30	M20	4	2	M20x30	4.95	19	68	56	70	35	16	3.5	1
8-LG-LP-20×120	M20x120	4	2	M20x120	4.95	19	78	65.5	85	40	18	3.5	1.5
8-LG-LP-24	M24	6.3	3.15	M24x40	57	22	78	65.5	85	40	18	3.5	1.5
8-LG-LP-24×40	M24x40	6.3	3.15	M24x90	57	22	78	65.5	85	40	18	3.5	1.5
8-LG-LP-24×90	M24x90	6.3	3.15	M24x90	57	22	78	65.5	85	40	18	3.5	1.5
8-LG-LP-24×120	M24x120	6.3	3.15	M24x120	57	22	78	65.5	85	40	20	3.5	1.5
8-LG-LP-27×35	M27	6.3	3.15	M27x35	57	22	96.5	80.5	85	40	20	4	1.5
8-LG-LP-30×35(5T)	M30(5T)	10.6	5.3	M30x35	66	23.5	96.5	80.5	85	40	20	4	1.5
8-LG-LP-30×38(5T)	M30x38	10.6	5.3	M30x38	66	23.5	96.5	80.5	85	40	22	4	1.5
8-LG-LP-30×120(5T)	M30x120	10.6	5.3	M30x120	66	23.5	112	92	115	50	22	6	2
8-LG-LP-30×35(8T)	M30(8T)	11.8	8	M30x35	80	28	112	92	115	50	22	6	2
8-LG-LP-30×38(8T)	M30x38	11.8	8	M30x38	80	28	112	92	115	50	22	6	2
8-LG-LP-30×120(8T)	M30x120	11.8	8	M30x120	80	28	109	89.5	115	50	22	6	2
8-LG-LP-36×90	M36x90	11.8	8	M36x90	80	27	109	89.5	115	50	22	6	2
8-LG-LP-36×40	M36x400	11.8	8	M36x400	80	27	109	89.5	115	50	22	6	2
8-LG-LP-39×50	M39	11.8	8	M39x50	80	27	109	89.5	115	50	22	6	2
8-LG-LP-39×90	M39x90	11.8	8	M39x90	80	27	109	89.5	115	50	22	6	2.5
8-LG-LP-42×50	M42	15	10	M42x50	80	27	109	89.5	115	50	25	6	2.5
8-LG-LP-42×60	M42x60	15	10	M42x60	80	27	109	89.5	115	50	25	6	2.5
8-LG-LP-42×130	M42x130	15	10	M42x130	80	27	109	89.5	115	50	25	6	2.5
8-LG-LP-42×180	M42x180	15	10	M42x180	80	27	109	89.5	115	50	25	6	2.5
8-LG-LP-45×60	M45x60	15	10	M45x60	80	27	109	89.5	115	50	25	6	2.5
8-LG-LP-48×50	M48	15	10	M48x50	80	27	109	89.5	115	50	25	6	2.5
8-LG-LP-48×110	M48x110	15	10	M48x110	80	27	109	89.5	115	50	25	6	2.5
8-LG-LP-56×84	M56x84	25	15	M56x84	117	42	310	280	152	70	32	7	2.5
8-LG-LP-64×95	M64x95	25	15	M64x95	117	42	310	280	152	70	32	7	2.5
