Name: LGRIG® Round Pin Chain Shackle US Type
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

 LGRIG® Screw Pin Chain Shackle High Tensile U.S. Type

 LGRIG® Screw Pin Anchor Shackle High Tensile U.S. Type

 LGRIG® Bolt Type Anchor Shackle High Tensile U.S. Type

 LGRIG® Bolt Type Chain Shackle High Tensile U.S. Type

 LGRIG® Nonrated Screw Pin Anchor Shackle U.S. Type

 LGRIG® Commercial Screw Pin Dee Shackle European Type

 LGRIG® Commercial bow Shackle with Screw Pin European Type

 LGRIG® JIS Type Screw Pin D Commercial Shackle

 LGRIG® Grade S Bow Shackle Screw Pin AS2741

 LGRIG® Grade S Dee Shackle with Screw Pin AS2741

 LGRIG® AS2741 Grade S Bow Shackle with Safety Pin&Nut

 LGRIG® AS2741 Grade S Dee Shackle Safety Pin & Nut

 LGRIG® Mooring Shackle No 852 Bolt Type Pin

 LGRIG® Grade 8 Alloy Bolt Type Anchor Shackle

 LGRIG® Grade 8 Alloy Bolt Type Chain Shackle

 LGRIG® Wide Body Sling Shackle Safety Pin Forged Alloy Steel

 LGRIG® Grade 80 Alloy Screw Pin Anchor Shackle

 LGRIG® Grade 8 Alloy Screw Pin Chain Shackle

 LGRIG® B.S.3032 Small Bow Shackle with Screw Collar Pin

 LGRIG® BS3032 Small Dee Shackle with Type A Screw Collar Pin

 LGRIG® B.S.3032 Large Bow Shackle with Screw Collar Pin

 LGRIG® BS3032 Large Dee Shackle with Type A Screw Collar Pin

 LGRIG® Shackles Similar to Din 82101 Form A/B/C Galvanised

 LGRIG® Italy Type Galvanized Bow Shackle Screw Pin

 LGRIG® Galvanized Dee Shackles Italy Type

 LGRIG® Round Pin Anchor Shackle U.S. Type

 LGRIG® Round Pin Chain Shackle US Type

 LGRIG® Piling Shackle Long D Shackle

 Trawling Shackle D Type Blue Painted Square Head Pin of Lifting & Rigging Shackles

 Trawling Shackle Bow Type Square Head Pin Blue Painted of Lifting & Rigging Shackles

 Bow Shackle Square Head Pin High Tensile of Lifting & Rigging Shackles

 Dee Shackle Square Head Pin for Lifting and Rigging Shackles

 Bow Shackle Sunken Head of Lifting & Rigging Shackles

 Dee Shackle Sunken Head of Lifting & Rigging Shackles

 LGRIG® G80 Unilock Shackle Connecting Link

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Building Components

 

Information of LGRIG® Round Pin Chain Shackle US Type

Brand	LGRIG®
Standard	Meet the performance requirements of Federal Specification RR-C-271F Type IVA, Grade A, Class 1
Model	G-215
Pin Type	Round Pin
Material	Body: Super Carbon Steel Round Pin: Alloy Steel / Super Carbon Steel
Safety Factor	6 : 1 / 4 : 1
Processing	Body: Drop Forged / Quenched and Tempered Round Pin: Cold/Hot Forged / Drop Forged / Quenched and Tempered
Finish	Body: Hot Dipped Galvanized / Powder Coated / Zinc Plated Round Pin: Powder Coated / Zinc Plated
Size	1/4”, 5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4”, 7/8”, 1”, 1-1/8” 1/1/4”, 1-3/8”, 1-1/2”, 1-3/4”, 2”, 2-1/2”, 3”, 3-1/2”, 4”
Tips	Special specification and marks can be made according to customers’ requirements

Specifications of LGRIG® Round Pin Chain Shackle US Type


Part No.	Size	Pin Diameter	Dimensions in inches	WLL	Weight
Part No.	S	A(in)	C	Tons	lbs
LG215RPDS1/4	1/4″	0.31	0.91	0.47	0.5
LG215RPDS5/16	5/16″	0.38	1.07	0.53	0.75
LG215RPDS3/8	3/8″	0.44	1.28	0.66	1
LG215RPDS7/16	7/16″	0.5	1.48	0.75	1.5
LG215RPDS1/2	1/2″	0.63	1.66	0.81	2
LG215RPDS5/8	5/8″	0.75	2.04	1.06	3.25
LG215RPDS3/4	3/4″	0.88	2.4	1.25	4.75
LG215RPDS7/8	7/8″	1	2.86	1.44	6.5
LG215RPDS1	1″	1.13	3.24	1.69	8.5
LG215RPDS1-1/8	1 1/8″	1.25	3.61	1.81	9.5
LG215RPDS1-1/4	1 1/4″	1.38	3.97	2.03	12
LG215RPDS1-3/8	1 3/8″	1.5	4.43	2.25	13.5
LG215RPDS1-1/2	1 1/2″	1.63	4.87	2.38	17
LG215RPDS1-3/4	1 3/4″	2	5.82	2.88	25
