Master links are a key component of multi-legged wire rope bridle slings, stingers, alloy chain slings and web sling bridles.
Pear Shaped Link A-341 Alloy Steel Grade 80, used as stand alone rigging accessories and can also be added to rigging configurations as needed.
These Pear Shaped Links may be used for the same applications as oblong master links, but their design is not optimum for multiple branch slings and, in some cases, may interfere with the crane hook. Perfect for a wide variety of lifting applications as Master Link.
Alloy A-341 pear shaped link, Suitable for use with G80 chain.
Technical Notes | US Federal Specification |
Material | Superior Alloy steel |
Processing | Drop Forged |
Finish | Powder Coated |
Size | 3/8”, 1/2”, 5/8”, 3/4”, 7/8”, 1”, 1-1/4”, 1-3/8”, 1-1/2”, 1-3/4”, 2” |
Safety Factor | 5:1 |
Tips | G80 components. Suitable for use with G80 chain. |
Part No. | Diameter | Inside | Inside Width | Each | W.L.L (Single Pull) | |
Small end | Large end | Alloy | ||||
Alloy | inch | inch | inch | inch | lbs | lbs |
LG-PL-3/8 | 3/8” | 2.25 | 0.75 | 1.5 | 0.23 | * |
LG-PL-1/2 | 1/2” | 3 | 1 | 2 | 0.55 | 7000 |
LG-PL-5/8 | 5/8” | 3.75 | 1.25 | 2.5 | 1.1 | 9000 |
LG-PL-3/4 | 3/4” | 4.5 | 1.5 | 3 | 1.95 | 12300 |
LG-PL-7/8 | 7/8” | 5.25 | 1.75 | 3.5 | 2.78 | 14000 |
LG-PL-1 | 1” | 6 | 2 | 4 | 4.3 | 24360 |
LG-PL-1-1/4 | 1-1/4” | 7.75 | 2.5 | 5 | 8.5 | 36000 |
LG-PL-1-3/8 | 1-3/8” | 8.25 | 2.75 | 5.5 | 11.5 | 43000 |
LG-PL-1-1/2 | 1-1/2” | 9 | 3 | 6 | 15.25 | 54300 |
LG-PL-1-3/4 | 1-3/4” | 10.5 | 3.5 | 7 | 22.5 | 84900 |
LG-PL-2 | 2” | 12 | 4 | 8 | 34 | 102600 |
China LG Supply provide you High Strength Forged & Welded Alloy Steel Master Link for use in grade 80 & grade 100 chain slings. Perfect for a wide variety of lifting applications.
