Name: Stainless Steel Wire Rope Thimble Heavy Duty G-414 LG RIGGING®
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

Stainless Steel Products

 

Shade Sail Hardware 

Stainless Shackles 

Stainless Turnbuckle 

Stainless Eye Bolts & Nuts 

Stainless Thimbles 

 Tubular Thimble Stainless Steel without Gusset G5 LG RIGGING®

 Tube Thimble Cast Stainless Steel without Gusset LG RIGGING®

 Tubular Thimble Stainless Steel Light Duty LG RIGGING®

 Tube Thimble Stainless Steel Heavy Duty LG RIGGING®

 Tubular Thimble Cast Stainless Steel with Gusset LG RIGGING®

 Tube Thimble Stainless Steel with Gusset G8K LG RIGGING®

 Stainless Steel Wire Rope Thimble Heavy Duty G-414 LG RIGGING®

 Stainless Steel Wire Rope Thimble Light Duty G-411 LG RIGGING®

 Stainless Steel Wire Rope Thimble European Type LG RIGGING®

 Stainless Steel Wire Rope Thimble Italian Type LG RIGGING®

Stainless Rings 

Stainless Swivels 

Stainless Quick Link 

Stainless Wire Clips 

Stainless Hooks & Clips 

Stainless Terminals 

Stainless U Bolts 

Stainless Hinge 

Stainless Pulleys 

Drop Forged Stainless Products 

Stainless Chains 

Eye Plate, Eye Straps, Angles 

Boat Fittings

 

Pole Line Hardware

 

Information of Stainless Steel Wire Rope Thimble Heavy Duty G-414 LG RIGGING®

Brand	LG RIGGING®
Standard	Meets or exceeds ASTM A148 & ASME B30.26 requirements.
Type	G-414
Material	Type 316 or 304 Stainless steel
Processing	Machining / Stamping
Finish	Highly Polishing
Size-Wire	1/8", 3/16", 1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8", 23/32", 3/4", 7/8", 1", 9/8"-5/4", 5/4"-11/8", 11/8"-3/2"

Specifications of Stainless Steel Wire Rope Thimble Heavy Duty G-414 LG RIGGING®

Specifications of Thimble Wire Rope G-414 Heavy Duty Stainless Steel

Part No.	Size		E	C	D	A	B	F	Weight
Part No.	in	mm	mm						g
LGSSG4141/8	1/8”	3	6.2	15	23	29	38.6	1.2	8.9
LGSSG4143/16	3/16”	4	7.4	18	26.5	33	42.6	1.2	11.8
LGSSG4141/4	1/4”	6	9	22.2	36	42.5	56	1.5	28
LGSSG4145/16	5/16”	8	11	27	44.8	48	63.6	2	54
LGSSG4143/8	3/8”	10	13	28.5	51.6	50	72	3	118
LGSSG4147/16	7/16”	11	14	32	54.5	57	78.7	3	140
LGSSG4141/2	1/2”	12	16	38	65	70.5	95	4	242
LGSSG4149/16	9/16”	14	18	42	70	76	104	4	274
LGSSG4145/8	5/8”	16	21	47	77	80	106	4	310
LGSSG41423/32	23/32”	18	21.2	48.5	88	86.3	115	5	507
LGSSG4143/4	3/4”	20	23.6	50	94	86	125	5	607
LGSSG4147/8	7/8”	22	28	58	104	95.5	137	6	923
LGSSG4141	1”	25	–	63.5	–	–	–	6	1221
LGSSG4149/8-5/4	9/8”-5/4”	28-31	39	76	142	116	280	6	1714
LGSSG4145/4-11/8	5/4”-11/8”	31-35	–	89	–	165	–	10	4005
LGSSG41411/8-3/2	11/8”-3/2”	35-38	–	89	–	–	–	10	4005
