Name: Tube Thimble without Gusset TTG7 Painted/Galvanized LG RIGGING®
Brand: QINGDAO LG RIGGING CO.,LTD.
Availability: InStock
Rating: 4.4 (1 reviews)

 Products

Trawling Gear

 

Lifting & Rigging

 

G100 Products 

G80 Products 

Turnbuckles 

Shackles 

Eye Bolts & Nuts 

Rigging Hooks 

Swivels 

Forged Rings & Connector 

Quick Links 

Snap Hooks 

Wire Rope 

Wire Rope Thimbles 

 Wire Rope Thimble Galvanized Commercial European Type LG RIGGING®

 Heavy Duty Wire Rope Thimble Galvanized US Type LG RIGGING®

 Wire Rope Thimble Light Duty Galvanized US Type LG RIGGING®

 Wire Rope Thimble DIN 6899 A Galvanized LG RIGGING®

 Wire Rope Thimble DIN 6899 B Galvanized LG RIGGING®

 Wire Rope Thimble BS464 Galvanised HDG EN13411-1/DIN3090 LG RIGGING®

 Wire Rope Thimble AS1138

 Tubular Thimble Galvanized without Gusset of Wire Rope Thimbles

 Tubular Thimble G2 Type for Trawling and Fishing of Wire Rope Thimbles

 Tube Thimble with Gusset TG2K LG RIGGING®

 Tubular Thimble SCG Type of Wire Rope Thimbles

 Tube Thimble without Gusset TTG7 Painted/Galvanized LG RIGGING®

 Synthetic Rope Thimble Galvanized

 Round Rope Thimble

 Manila Rope Thimble Galvanized

 DIN 3091 Solid Thimble for Wire Rope Casting

 JIS Standard Wire Rope Thimble

 K2 Heavy Duty Stub-End Thimble of Wire Rope Thimbles

 Heavy Duty Wire Rope Thimble K2-B

 Wire Rope Thimble K3-B with Ear&Master Link

 K3 Fibre Rope Thimble of Wire Rope Thimbles

 Galvanized Superloop Thimble Type K15 of Wire Rope Thimbles

Wire Ropes Clips & Grips 

Wire Rope Sleeves/Ferrules 

Chains & Accessories 

Chain Binders 

Ratchet Straps 

Lifting Sling of Lifting & Rigging 

Lever Hoist 

Pulley & Blocks 

Lifting & Rigging Pins 

Forestry Logging Supplies 

Eye Plate 

Stainless Steel Products

 

Boat Fittings

 

Pole Line Hardware

 

Information of Tube Thimble without Gusset TTG7 Painted/Galvanized LG RIGGING®

Brand	LG RIGGING®
Material	Superior Carbon Steel
Processing	Machining / Stamping
Finish	Zinc Plated, Hot Dip Galvanized, Powder Coated
Size	G712, G715, G717, G719, G722, G725, G728, G730, G735, G745, G750
for Wire	12-10mm, 15-12mm, 17-14mm, 19-16mm, 22-18mm, 55-22mm, 28-24mm, 30-26mm, 35-32mm, 45-38mm, 50-42mm, 55-48mm
Tips	Supplied in open finish or with welded gusset plate

Specifications of Tube Thimble without Gusset TTG7 Painted/Galvanized LG RIGGING®

Specifications of Wire Rope Tubular Thimble Galvanized SCMG Type-China LG™

Part No.	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	Weight (kg)	Rope Diameter
LGTTG712	12	84	23	4	8	0.21	10
LGTTG715	15	95	27	5	10	0.4	12
LGTTG717	17	100	27	5	10	0.48	14
LGTTG719	19	112	32	5	12	0.6	16
LGTTG722	22	125	35	5	15	0.71	18
LGTTG725	25	150	45	6.3	16	1.21	22
LGTTG728	28	157	45	7	16	1.6	24
LGTTG730	30	170	47	7	18	1.91	26
LGTTG735	35	190	60	7	22	2.6	32
LGTTG745	45	228	70	7	27	3.5	38
LGTTG750	50	255	75	7	35	4.2	42
LGTTG755	55	268	80	7.5	31	4.8	48
