Information of Tubular Thimble Stainless Steel without Gusset G5 LG RIGGING®

Brand	LG RIGGING®
Material	Type 316 or 304 Stainless Steel
Processing	Machining / Stamping
Finish	Highly Polishing
Size	G512, G515, G521, G527, G532
for Wire	12mm, 15mm, 21mm, 27mm, 32mm

Specifications of Tubular Thimble Stainless Steel without Gusset G5 LG RIGGING®


Part No.	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	Weight (KG)
LGSSTTG512	12	90	21	2.4	10	0.15
LGSSTTG515	15	100	23	2.8	12	0.21
LGSSTTG521	21	116	27	2.8	14	0.33
LGSSTTG527	27	145	36	3.2	18	0.60
LGSSTTG532	32	182	46	3.3	21	–
