Information of Wire Rope Thimble DIN 6899 B Galvanized LG RIGGING®

Brand	LG RIGGING®
Standard	DIN6899/B
Material	Superior Mild Steel
Processing	Machining / Stamping
Finish	Electric Galvanized
Size	3mm, 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 22mm, 24mm, 28mm, 30mm, 32mm

Specifications of Wire Rope Thimble DIN 6899 B Galvanized LG RIGGING®

Specifications of DIN 6899 B Galvanized Wire Rope Thimble

Part No.	Nominal Size	Rope (Ø)	D	H	B	Weight
Part No.	mm	mm	mm	mm	mm	kgs/pc
LG6899B03	3	2.5-3.0	12	19	3	0.006
LG6899B04	4	3.0-4.0	13	21	4	0.007
LG6899B05	5	4.0-5.0	14	23	5	0.009
LG6899B06	6	5.0-6.0	16	25	6	0.013
LG6899B08	8	7.0-8.0	20	31	8	0.027
LG6899B10	10	8.0-10.0	23	39	10	0.037
LG6899B12	12	10.0-12.0	28	44	12	0.066
LG6899B14	14	12.0-14.0	32	53	14	0.081
LG6899B16	16	14.0-16.0	36	58	16	0.126
LG6899B18	18	16.0-18.0	40	64	18	0.229
LG6899B20	20	18.0-20.0	45	72	20	0.298
LG6899B22	22	20.0-22.0	48	78	22	0.347
LG6899B24	24	22.0-24.0	53	88	24	0.659
LG6899B26	26	24.0-26.0	60	99	26	0.729
LG6899B28	28	26.0-28.0	65	111	28	0.887
LG6899B30	30	28.0-30.0	75	120	30	0.949
LG6899B32	32	30.0-32.0	78	124	32	1.12
